4. Technical data

AC motor: ................................230-240 V ~ 50Hz
Power: ........................................1600 W S6 20%
Idle speed n : ....................................... 5000 rpm
0
Carbide saw blade: ...........ø 210 x ø 30 x 2.8 mm
Number of teeth: ............................................ 48
Swiveling range: ............................ -47° / 0°/ +47°
Miter cut to the left: .................................0° to 45°
Miter cut to the right: ...............................0° to 45°
Saw width at 90°: ............................ 310 x 65 mm
Saw width at 45°: ............................ 210 x 65 mm
Saw width at 2 x 45°
(double miter cut left): ...................... 210 x 35 mm
Saw width at 2 x 45°
(double miter cut right): ................... 210 x 20 mm
Workpiece length, min.: .......................... 180 mm
Weight: .......................................... approx. 13 kg
Laser class: ...................................................... 2
Wavelength of laser: ................................ 650 nm
Laser output: ........................................... ≤ 1 mW
Protection class: ............................................ II/
Operating mode S6 20%: Continuous operation
with idling (cycle time 10 minutes). To ensure that
the motor does not become excessively hot, it
may only be operated for 20% of the cycle at the
specifi ed rating and must then be allowed to idle
for 80% of the cycle.
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
L sound pressure level ..................... 95,1 dB(A)
pA
K uncertainty ............................................. 3 dB
pA
L sound power level ..................... 108,1 dB(A)
WA
K uncertainty ............................................. 3 dB
WA
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 61029.
Vibration emission value a
K uncertainty = 1.5 m/s
Anl_TE_SM_2131_Dual_SPK7.indb 25 Anl_TE_SM_2131_Dual_SPK7.indb 25
= 4.58 m/s
2
h
2
- 25 -
GB
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
