Heater Installation

The heater can be placed wherever in the sauna, but for safety and convenience, follow
the minimum safety distances as provided in Fig. 2. Follow the cubic volumes given in the
Technical Diagram (page 12.). Do not install the heater to the floor or wall niche. Do not
install more than one heater in a sauna room unless you follow the special instructions for
twin-heater installations. In most countries, there is a law that requires heaters to be
screwed to the floor as provided in Fig. 1a. Install bracket support for safety purposes
Fig. 1b.
The heater gets very hot. To avoid the risk of accidental contact with the heater, it is
recommended that a heater guard be provided.
The cable used for sauna wiring must be HO7RN-F type or its equivalent. A certified
electrician must do the installation of the heater to ensure safety and reliability. Improper
electrical connection can cause electric shock or fire. Refer to the electrical diagram in
page 6.
Mindest Sicherheitsabstände (mm)
Abb. 2
Fig. 2 Minimum Safety Distances (mm)
A
TH2-30NB
TH3-35NB
TH3-45NB
TH3-60NB
TH2-30NS
TH3-35NS
TH3-45NS
TH3-60NS
TH4-60NB
TH4-60NS
TH4-80NS
TH5-90NS
A
A B
TH6-80NB
150 1900
TH6-90NB
150 1900
TH6-80NS
150
1900
TH6-90NS
150
1900
TH6-105NS
150 1900
TH6-120NS
100 1900
100 1900
150 1900
150 1900
150
1900
1900
200
200 1900
HINWEIS:
Die maximale Leistung entnehmen Sie
100
bitte der Bedienungsanleitung für die
Steuerung. Wenn die Leistung des
Ofens die Leistungsstärke der
separaten Steuerung überschreitet,
wird ein Leistungsschütz benötigt.
Weitere Leistungs-Schütze können bei
den Öfen mit 10,5kW oder höher
B
angeschlossen werden.
NOTE:
Please refer to the control unit
manual for maximum power rating.
Contactor unit is needed if heater's
power rating exceeds separate
control unit's capacity. Additional
contactor unit can be connected to
20
the heaters 10,5kW and higher.
100 1900 TH9-105NS
100 1900 TH9-120NS
100 1900 TH9-150NS
100
1900 TH9-180NS
150 1900 TH12-150NS
200 2100 TH12-180NS
TH12-210NS
TH12-240NS
150 2100
150 2100
200 2100
200
2100
200 2300
200 2300
200 2300
200 2300
9
