5.2 Explanation of the display
A
F
A - Displays the day of the week.
B - The actual clock time is displayed here.
C - Indicates the temperature (°C) measured.
D - Indicates the number of minutes before the overtime timer function is switched off again and
the PinTherm Infra adjusts to the night-time temperature.
E - Indicates whether the PinTherm Infra is in the day-time (DAY) or night-time position
(NIGHT) and is adjusted based on the day or night-time temperature.
F - Whenever the high/low function is set to automatic in the menu, this is displayed here
(1K, 2K of 3K).
5.3 Initial commissioning of the PinTherm Infra
When you set the voltage on the PinTherm Infra for the first time, you will be asked to select the
language required and then to set the time and date. The PinTherm Infra then goes back to the
main screen and the "heating" and "high" function is switched on.
SELECT LANGUAGE
ENGLISH
select the desired
language
Language options: NL, EN, DE, FR, IT, PL, RO, LT.
B
MON 08:01
1K DAY
E
SAT 01-01-2006
00:00:00
OK
MON
C
16°C
X:060
D
OK
changes the
ashing digit
to go one digit up
08:00 16°C
DAY
EN
