cycle time (PERIOD): if your system is used exclusively with digital servos, you can set a cycle time
(frame rate) of 10 ms at this point. If your system includes some or all analogue servos, you should
always select 20 ms, as many analogue servos cannot process the higher frame rate, and may respond
by "jittering" or "growling".
hott sum signal (sUMD): if you activate the digital sum signal at channel 8, a sum signal containing
eight channels is present at this socket, instead of a servo signal. The HoTT receiver configured as
SUMD constantly generates a digital sum signal from 8 control signals from the transmitter and makes
this signal available at the appropriate servo socket, which is receiver-specific. At the time these
instructions were revised, this type of signal is used by several of the latest electronic developments in
the area of flybarless systems, heavy-duty airborne power supplies, etc.
WARNING: if you wish to use this facility, it is essential to observe the set-up information
supplied with the devices connected to the receiver, otherwise there is a risk that your model
may be uncontrollable!
MENU ItEM ONlY At 33579 GR-18 PRO 3XG +3 A + VARIO
Telemetry sensor (sensor at K9): This jack allows you to use either for telemetry or for an extra channel
(9). (Note: Both together is not possible!) Switching is done in this menu item. If you select „Yes", the
socket is connected to the connection of a sensor. If you select „No" a jack is connected to the control
channel 9.

3.3 FREE MIXERs

RX FREE MIXER
>MIXER:
MASTER CH:
SLAVE CH:
>TRIM:
>TRAVEL-:
TRAVEL+:
screen Display
MIXER
FROM CHANNEL
TO CHANNEL
TRIM
TRAVEL-
TRAVEL+
MIXER: up to four mixers can be programmed simultaneously. You can switch between Mixer 1, Mixer
2, ... and mixer 4 in the "Mixer" line.
The following settings only affect the mixer selected in this line.
FROM chANNEl: the signal present at the signal source (or source channel) is mixed in to the target
channel (TO CHANNEL) to an extent which can be set by the user. The method of setting up the values
is analogous to the "Free mixers" menu in HoTT transmitters.
Manual Receiver GR-18/24PRO
< >
1
1
tures a V-tail, or has two elevator servos, you must use the
6
receiver mixer - not the transmitter mixer - to control these
+0%
control surfaces, since the gyro stabilisation system will
+100%
have no effect on these servos otherwise. the four receiver
+100%
mixers work 'downstream' of the gyros. if you have already
programmed mixer functions in the "wing mixers" or "Free
mixers" menu of your hott transmitter, you must ensure that
those mixers do not overlap with those available in this menu!
key
Mixer select
Signal source / source channel
Target channel
Trim position in %
Travel limit at % Servo travel
Travel limit at % Servo travel
important note:
if you wish to use the gyros, you
must always set the tail type to 'normal' in the trans-
mitter's model type menu. if your model is a delta, fea-
settings
1, 2....4
0,1,2,...6
0,1,2,...6
-15 - + 15%
-150 bis +150%
-150 bis +150%
