er running Windows Vista (or
o input/output, proceed as
on uses Windows Vista as an
M H4 ASIO driver from the
ation (http://www.zoom.co.jp)
oftware is required to enable use of
d output with a computer. Refer to the
ownload package for instructions on
y.
4n is not up to date, the H4n may not
computer. You should always upgrade
st version. The latest version can also
ite of ZOOM Corporation.
ase LE 4" DVD-ROM into the
er, and perform the
M, a screen asking what you want to do
view files".
-ROM are shown, open the "Cubase
ouble-clicking on it, and then double-
etup.exe") file to start the installation
sert the DVD-ROM, open the Start
My Computer" in Windows XP). Then
" DVD-ROM icon to display the
e LE 4 is complete, a screen asking
software license authentication)
. Install this software, because it is
LE 4.
computer using a USB cable.
ther instrument or built-in stereo mic
Computer
1]/[INPUT 2] jack
USB cable
Audio system or
other hi-fi playback
equipment
H4n to enable USB connection. The
computer. If this is the first time to
message "Your devices are ready to
[PHONES/LINE] jack of the H4n to monitor the signal.
• Use a high-quality USB cable and keep the connection as short as
possible. If USB bus power is supplied to the H4n via a USB cable
that is more than 3 meters in length, the low voltage warning
indication may appear.
Bring up the "Sound" window from the Control Panel
and make the input device setting for the computer.
To bring up the "Sound" window, select "Control Panel" from the
Start menu and click "Hardware and Sound", then click "Sound".
In the "Sound" window, verify that "H4 Audio" is listed under the
Play and Record devices and that the device is checked. (To switch
between Play and Record, click the tabs at the top of the window.)
If the device is not checked, right-click on the icon for the device and
click "Set as Default Device" so that a check mark appears.
Start Cubase LE 4. Then access the "Devices" menu,
select "Device Setup..." and click "VST Audio
System".
To start Cubase LE 4, double-click the Cubase LE 4 shortcut icon that
was created on the desktop. After startup, select "ZOOM H4 ASIO
Driver" as the ASIO driver in the right section of the Device Setup
window. When you change the ASIO driver selection, a confirmation
message appears. Click the "Switch" button.
ASIO driver
The device indication in the left section of the window now shows
"ZOOM H4 ASIO Driver" as the ASIO driver.
Click on this indication to select it, and then click the "Control Panel"
button in the right section of the Device Setup window.
Then click here
Click here...
The window that appears lets you set the latency and sampling
frequency for the ASIO driver. The latency should be set to a value
that is as low as possible without causing sound dropouts during
To connect the H4n to a computer running MacOS X and enable
audio input/output, proceed as follows.
Insert the supplied "Cubase LE 4" DVD-ROM into the
DVD drive of the Macintosh.
The contents of the DVD-ROM appear automatically. If nothing
happens when you insert the DVD-ROM, double-click the "Cubase LE
4" icon shown on the desktop.
Install Cubase LE 4 on the Macintosh.
When the contents of the DVD-ROM appear, open the "Cubase LE 4
for MacOS X" folder by double-clicking it, and then double-click the
"Cubase LE 4.mpkg" file to start the installation process.
Connect the H4n to the computer using a USB cable.
Guitar or other instrument or built-in stereo mic
AC adapter
[INPUT 1]/[INPUT 2] jack
or H4n
USB cable
[PHONES/LINE] jack
Batteries
Take the required steps at the H4n to enable USB connection. The H4n
will be recognized by the computer.
HINT
For information on steps to take at the H4n, see the section "Setting
up: USB connection, H4n used as an Audio Interface" (p.033) of the
H4n operation manual.
NOTE
• If you monitor the audio signal during recording via the audio output
of the computer, there will be an audible delay. Be sure to use the
[PHONES/LINE] jack of the H4n to monitor the signal.
• Use a high-quality USB cable and keep the connection as short as
possible. If USB bus power is supplied to the H4n via a USB cable
that is more than 3 meters in length, the low voltage warning
indication may appear.
Open the "Applications" folder and then the "Utilities"
folder, and double-click "Audio MIDI Setup".
The Audio MIDI Setup screen appears. Click "Audio Devices" and
check whether "H4 Audio" is selected as default input/default output.
If another device is sel
selection to "H4 Audio"
When the setting has be
Start Cubase LE 4.
select "Device Set
System".
To start Cubase LE 4, d
placed in the "Applicatio
After startup, be sure to
driver in the right sectio
Macintosh
Audio system or
other hi-fi playback
equipment
If another item is selec
selection to "H4 Audio (
When the setting has b
window.
