or Mac OS X) left to switch between
t "Zm In (Out)" is selected as device
cted, click the device port field and
and select "New Project".
ears. Here you can select a project
ty" template is selected, and
ect file save location appears.
e project file save location
ick the OK button (Choose
e project window for controlling most
ppears.
ack, access the "Project"
ack". In the submenu that
fying the number of audio tracks and
Select stereo/mono setting
Make the following settings for the newly created
audio track.
If the Inspector is not shown, click here to
toggle the Inspector show/hide setting.
Inspector (area for making detailed
track settings)
Select the input/output path for the track.
(The path name assigned to the H4n in
step 6 is shown here.) To select a different
path, click this section and select a new
path from the menu that appears.
HINT
The Inspector shows information about the currently selected track. If
nothing is shown, click on the track to select it.
Connect the guitar or other instrument to the [INPUT]
jack of the H4n and select the desired patch.
The sound selected here will be recorded on the computer via the
[USB] port. For information on how to select the input signal and
effect patch for the H4n, see page 034 (Selecting the input source) and
page 083 (Selecting a patch) of the H4n operation manual.
Access the "Devices" menu of Cubase LE 4 and
select "Mixer".
The mixer window appears.
This window shows the channel assigned to the created track, and the
master channel.
Perform the following steps here.
Mixer window
Click monitoring button so
that it lights up in orange.
Click recording standby
button so that it lights up in
red, to activate recording
standby condition.
of the H4n to achieve a suitable recording level for
Cubase LE 4.
The recording level for Cubase LE 4 can be checked with the level
meter for the channel that is assigned to the recording standby track.
Set the level as high as possible without causing the meter to reach the
end of the scale.
To adjust the level, do not use the fader of Cubase LE 4. Instead
change the recording level and gain settings at the H4n.
NOTE
• While the monitoring button is enabled, the direct signal input to the
H4n and the signal routed to the computer and then returned to the
H4n will be output simultaneously from the H4n, causing a flanger-
like effect in the sound. To accurately monitor the sound also while
adjusting the recording level, temporarily set the output device port
for the VST connection (step 6) to "Not Connected".
• The level meter as in the above illustration shows the signal level
after processing in the H4n. When you pluck a guitar string the
meter may register with a slight delay, but this is not a defect.
When the recording level has been adjusted, click the
monitoring button to disable it.
The input level is no longer shown on the meter, and the signal
returned to the H4n via the computer is muted.
In this condition, only the signal before sending to the computer can
be monitored via the [PHONES/LINE] jack of the H4n.
Verify that the transport panel is being shown.
If the transport panel is not shown, access the "Transport" menu and
select "Transport Panel".
To start recording, click the Record button in the
transport panel.
Record button
Stop button
Recording starts.
As you play your instrument, the waveform appears in real time in the
project window.
To stop recording, click the Stop button in the transport panel.
1.
Move the fader of
the master channel
(as displayed in
step 13) fully
down.
Level meter
Go to beginning
2.
Use the button in
transport panel to m
to the beginning o
project.
HINT
If no sound is heard wh
check the VST connect
NOTE
To continue using Cub
authentication and prod
Cubase LE 4, a screen
Select "Register Now".
Internet browser. Follow
activate the product.
For optimum enjoym
While using Cubase LE 4,
drastically or a message su
interface" may appear. If th
following steps to optimize
(1) Shut down other app
In particular, check f
(2) Reduce plug-ins (eff
4.
When there is a high
processing power m
the number of tracks
helpful.
(3) Power the unit from
When a device desig
the USB port, the cu
leading to problems.
operation.
If applications still run ver
function properly, disconn
down Cubase LE 4. Then r
LE 4 again.
