Instructions for use
Automatic lock for upper section 16
Place the carrycot or stroller unit upon the chassis in a way that the two lateral
pins engage in the respective slots on each side. Then push the upper section
right up to the stop. The catching pins on both sides engage automatically,
which is indicated each time by a click sound.
WARNING!
By pulling the upper section, check before use whether it
is fixed securely! If the red safety point can still be seen, the upper-section
lock has not yet completely closed!
Pull the locking lever downwards until it snaps into place to open the lock
and to remove the upper section.
Parking brake
Push the red brake button 7 to enga-
ge the brake. Having parked the
13 13
pram, try to push it to check the
brake. Push the green brake button 7
WARNING!
to release the brake.
Make sure the brake is always closed
when placing the baby in the carriage
or taking it out of it.
8 8
Adjustable suspension system
7
By turning the selector 8, a "hard" or
"soft" position can be selected for suspension..
Adjusting the backrest
By lifting the back clip 13 at the rear, the backrest can be adjusted from sit-
WARNING!
ting to reclining position in close steps. When adjusting the
backrest, take care no movable parts jam the baby's limbs, or fingers, etc.
Finally, make sure the backrest has reengaged properly.
WARNING!
Fall-out protection
As an additional protection preventing the
baby from falling out of the carriage, secu-
17 17
re the hood to the metal back. To do this,
join the two hood grommets 17 to their
respective turn-lock fasteners, and the
hook locks 18 to the metal ring on the
18
cross tube at the rear as well.
13
