Ref. No. Part No.
DUNTKB173DE03
R/C RECEIVER UNIT
CAPACITORS
C5591 VCEAPF0JW107MY J 100
C5592 VCKYCY1EF104ZY J 0.1
RESISTORS
R5591 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R5592 VRS-CY1JF220JY J 22
MISCELLANEOUS PARTS
P5591 QPLGN0363TAZZY J Plug, 3-pin(RC)
RMC5591 RRMCU0239CEZZ J R/C Receiver
PSLDC3117CEFW J Shield
QCNW-A495WJZZ J Connecting Cord
Description Code
6.3V Electrolytic AC
å
25V Ceramic AA
å
AA
å
1/16W Metal Oxide AA
å
AC
å
AG
å
AD
AD å
å
å
å
å
å
157
Ref. No. Part No.
RUNTKA021WJZZ
AC INLET UNIT
DIODES
D701 95KUBA0005KZ J Diode
Z701 95KUER0002ZZ J Varistor
COILS
L701 95KUKZ1138ZZ J Inductor
L702 95KUKZ1138ZZ J Inductor
CAPACITORS
C701 95KUGFM474KR J 0.47
C702 95KUGFM474KR J 0.47
C703 95KUGZ1016ZZ J 4700p
C704 95KUGZ1016ZZ J 4700p
C758 95KUGZ1016ZZ J 4700p
C759 95KUGZ1016ZZ J 4700p
RESISTORS
R701 95KUEEC105CH J 470k 1/2W
R702 95KUEBZ3R9AD J 3.9
MISCELLANEOUS PARTS
RL701 95KPHZ0205ZZ J Relay
MT701 95KLRZ6866ZQ J Angle
MD702 95KGZZ5491ZZ J Shield
SC701 95KRAA3060AZ J Socket
SC702 95KRAB3060AB J Socket
SC703 95KRAZ4141ZT J Socket
F701 95KPJCTP1002 J Fuse, 10A/250V
CN701 95KPZZ1018ZZ J Inlet
CN702 95KPKZ1135ZZ J Connector, 3-pin
CN703 95KPKZ0741ZZ J Connector, 2-pin
CN709 95KEDB7717ZZ J Connector
