Operating Components - Silvercrest SAB 160 A1 - IAN 90468 Bedienungsanleitung

Figure B:
29
CD compartment
30
Theft protection LED/ CD compartment position LED
31
32 Holder for the face plate
RESET: Resetting the device
33
Figure C:
ISO-Block connection B
34
Automotive blade type fuse 10 A
35
ISO block connection A
36
Bluetooth antenna
37
GB
SUBWOOFER: Connection cable with cinch connector for subwoofer
38
Socket for microphone unit
39
LINE OUT: Audio cinch output L/R for amplifi er
40
Antenna connection for DIN antenna plug
41
Accessories (see rear fold out fl ap)
Figure D:
Microphone unit plug
42
Microphone
43
TALK button
44
green LED for connection status
45
Case for face plate
46
47
Bezel frame
48
Installation bracket
49
Key for installation bracket
50
Fixture plate (incl. securing material)
51
Adapter cable for ISO-Block A
168
button: Eject disc

Operating components

SAB 160 A1
