outlet.
2
Install the filters
1
Place the HEPA Filter
within the Filter Frame with
the tabs facing up.
Do not install the filter backwards or
the unit will not operate properly.
2
Place the Active Carbon Filter
on top of the HEPA Filter
with the bands (2 places)
facing up.
3
Place the Pre-filter through
the bands (2 places) located
in the corners of the Active
Carbon Filter.
Insert the tabs of the pre-filter into
the associated holes of the Filter
Frame.
4
Mount the Filter Frame to
the main unit.
5
Fix the Front Panel to the
main unit.
6
Fill in the usage start date
on the Date Label.
Use the date as a guide for the
Filter Replacement schedule.
HEPA Filter
Filter Frame
Band
Active Carbon Filter
HEPA Filter
Filter Frame
Band
Holes
Main unit
Filter Frame
Band
Date Label
E-7
Tabs
Tabs (4 places)
