1

General

1.1

Identification of Model Versions

Models: Automatic Spray Guns PILOT WA 110
Type: PILOT WA 110
Manufacturer: WALTHER Spritz-und Lackiersysteme GmbH
Kärntner Str. 18-30
D-42327 Wuppertal
Tel.: 00 49 202 / 787-0
Fax: 00 49 202 / 787-217
www.walther-pilot.de • Email: info@walther-pilot.de
1.2

Normal Use

The automatic spray gun PILOT WA 110 is exclusively designed for use with sprayable
materials.
• paints and lacquers
• greases, oils and corrosion preventives
• adhesive compounds
• separating agent
• ceramic glazes
• pickling solutions
Should the materials which you want to spray not be listed above, please contact
WALTHER Spritz-und Lackiersysteme for further and detailed information.
Plase note that sprayable materials may only be applied to work pieces and/or simi-
lar items. The temperature of the spraying materials shall never exceed 80 degrees
Celsius. The model of the serie PILOT WA 110 is not designed for manual operati-
on, and must be installed in a suitable gun mounting device.
The term normal use also implies that any and all safety warnings, operational
handling details, etc., as stated in these operating instructions, must be carefully
read, understood and duly complied with.
This equipment complies with the explosion protection requirements of Directive
94/9/EC (ATEX) for the explosion group, equipment category and temperature class
indicated on the type plate. When using the equipment, the requirements
specified in these Operating Instructions must be observed at all times.
The technical data indicated on the equipment rating plates and the specifications in
the chapter "Technical Data" must be complied with at all times and must not be
exceeded. An overloading of the equipment must be ruled out.
The equipment may be used in potentially explosive atmospheres only with the
authorisation of the relevant supervisory authority.
The relevant supervisory authority or the operator of the equipment are
responsible for determining the explosion hazard (zone classification).
The operator must check and ensure that all technical data and the marking of
2
V 20 340
the equipment in accordance with ATEX are compliant with the necessary require-
ments.
The operator must provide corresponding safety measures for all applications in
which the breakdown of the equipment might lead to danger to persons.
If any irregularities are observed while the equipment is in operation, the equipment
must be put out of operation immediately and WALTHER Spritz-und
Lackiersysteme must be consulted.
Grounding / Equipotential Bonding
You must ensure that the spray gun is properly earthed (grounded) either separate-
ly or in connection with the equipment with which it is being used (maximum resi-
6
stance 10 ).
1.3

Improper Use

This spray gun shall not be used for purposes other than set forth in the above
Chapter Normal Use. Any other form of use and/or application is prohibited.
Improper use is for example:
• spraying of material onto persons and animals
• spraying of liquid nitrogen, etc.
2

Technical Description

The automatic spray gun PILOT WA 110 works with compressed air control. The
atomizer air is controlled via an externally arranged pressure reducing valve. The
gun body is made of .14305.
3

Safety Instructions

• All applicable accident prevention rules and regulations as well as other recognised
industrial safety and health rules and regulations must be observed at all times.
• Use the spray gun only in well-ventilated rooms. Fire, naked flames and smoking are
strictly prohibited within the working area. WARNING – during the spraying of flam-
mable materials (e.g. lacquers, adhesives, cleaning agents, etc.), there is an increased
risk to health as well as an increased risk of explosion and fire.
• Measures must be taken to ensure that the spray gun is sufficiently grounded
(earthed) by means of a conductive air hose (maximum resistance 10 6 ).
• Before carrying out maintenance or servicing work, always ensure that the air and
material feed to the spray gun have been de-pressurised. Risk of injury!
• When spraying materials, do not place your hands or other parts of the body in front of
the pressurised nozzle or the spray gun. Risk of injury!
• Never point the spray gun at persons or animals. Risk of injury!
• Always observe the spraying and safety instructions given by the manufacturers of the
spraying material and the cleaning agent. Aggressive and corrosive materials in parti-
cular can be harmful to health.
• Exhaust air containing particles (overspray) must be kept away from the working area
and personnel. In spite of these measures, always wear the regulation breathing
masks and protective overalls when using the gun. Airborne particles represent a
serious health hazard!
3
