44 | English
Adjusting the Flush Levelling: (see figure C2)
– Turn thumbwheel 47 until the parallel laser
beam is flush to the desired cutting-line mark
over the complete length.
One rotation in anticlockwise direction moves
the laser beam from left to right; one rotation in
clockwise direction moves the laser beam from
right to left.
Mounting the Table Extension and the
Fences/Stops
Mounting the Table Extension (see figure D)
The table extension 27 is used to widen or ex-
tend the saw table 7. It can be mounted either
on the left or right side, or to the rear of the saw
table.
For assembly, use the fastening kit for the "table
extension" 48. (rotary knob 52, socket bolt, nut)
– Slide or insert the table extension 27 into the
desired guide groove 8 of the saw table.
When the table extension is mounted left or
right from the saw table, it is supported toward
the front.
When the table extension is mounted to the rear
of the saw table, it can be supported toward the
left or the right.
– Move the table extension until the lower
holding prongs of the support leg 49 are
aligned with one of the mounting holes 9.
If required, move the upper fastening plate of
the support leg 49.
For this, loosen both Allen screws 50 with Al-
len key 13, move the upper fastening plate
until the support leg 49 is aligned with the
desired mounting hole 9, and retighten the
Allen screws 50 again.
– Place the nut into the mounting hole 9 and
screw the holding prongs of the support leg
to the saw table with the socket bolt.
– Screw rotary knob 52 for locking the table ex-
tension into the bolt hole intended for it, and
tighten it.
The table extension must be flush with the saw
table surface.
– Adjust the correct height of the table exten-
sion 27 with rotary knob 51.
1 609 929 W71 | (30.3.11)
Mounting the Universal Guide (see figure E)
The universal guide 1 can be mounted left or
right on the saw table 7, or to the table exten-
sion 27.
Note: When sawing bevel angles, the universal
guide should be mounted to the right of the saw
blade.
– Slide or insert the extension plate 30 of the
universal guide into the desired guide groove
8 of the saw table or into the guide groove of
the table extension 27.
– Screw rotary knob 38 for locking the univer-
sal guide into the bolt hole intended for it,
and tighten it.
Mounting the Fence to the Universal Guide
The fence 36 of the universal guide is used as a
supporting surface for the workpiece.
When sawing narrow workpieces, the fence 36
should be mounted flush to universal guide 1 in
order to prevent jamming or slipping of the
workpiece. (see figure F1)
When sawing high workpieces and when saw-
ing with slide action, the fence 36 should be
mounted upright to the universal guide 1, so
that the supporting surface of the workpiece is
as large as possible. (see figure F2)
– Loosen wing bolt 34.
– Slide the fence 36 either upright or flat onto
the guide tongue 53 of the universal guide.
– Tighten wing bolt 34 again.
Mounting to a Working Surface
(see figure G)
To ensure safe handling, the machine must
be mounted on a level and stable surface
(e. g., workbench) prior to using.
– Fasten the power tool with suitable screw
fasteners to the working surface. The mount-
ing holes 9 serve for this purpose.
Bosch Power Tools
