Orfeo 100

1. INSTALLATION

1. Place the answering machine on a hard flat surface.
2. Insert a 9V battery (not delivered) into the battery compartment underneath
the device.
3. Insert the small plug of the adaptor in the back of the machine.
4. Plug the AC adaptor in the AC wall outlet.
5. Insert the small connector of the telephone cable into the answering machine
and plug the other end in the wall outlet of the telephone net.
6. You can start using your Orfeo 100 digital answering machine as soon as you
hear "Announcement one on".
2. BUTTONS
1. On/Off / Fast Forward button
2. Code/Erase button
3. Playback/Pause/Memo button
4. OGM/Rewind button
5. Time button
6. Microphone
7. LED On/Off + Message counter
8. LED Power/Battery low
9. LED Recording
10. Volume control
11. Connection telephone line
12. Connection adaptor AC 9V
10
34
11
6
7
8
9
5
3. SETTINGS
3.1. DAY/TIME SETTING
Proceed as follows to change the day & time setting:
1. Press the Time button for 1,5 sec. until the machine says which day it is
according to its present setting.
2. Press the Fast Forward button to select a following day or the Rewind button
to choose an earlier day. Each time you press one of these buttons, the
machine says which day you have selected.
3. If you have reached the right day, press the Time button to set the machine to
the selected day. Now the machine will say the hour to which it is set.
4. Press the Fast Forward button to select a later hour or the Rewind button to
select an earlier hour. Each time you press one of these buttons, the machine
says the hour you have selected.
5. If you have reached the right hour, press the Time button to confirm the
selected hour. Now the machine will say the minutes after the hour to which it
12
is set.
6. Press the Fast Forward button to select a later minute setting or press the
Rewind button to select an earlier minute setting. Each time you press one of
these buttons, the machine says which minute setting you have selected.
7. If you have reached the right minute setting, press the Time button to confirm
the selected minute setting.
8. The machine will say the set day, hour and minutes to confirm your settings.
Remark : If, during one minute, no button is pressed, the machine will
automatically leave the setting mode and return to the previous
1
mode.
2
3
4
Orfeo 100
35
