> Reorient or relocate the receiving antenna.
> Increase the separation between the equipment and receiver.
> Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
> Consult the dealer or an experienced radio/TV technician for help.

18. ProduCT suPPorT

Visit "http://www.rclogger.com/index.php/contact-us" or call +852 2559 2662 for product support.
Additionally visit our support forum at "http://rclogger.com/forum".

19. TeChnICal daTa

Transmitter
Transmission frequency:
Number of transmitter channels:
Transmitter range:
Supply voltage:
Dimensions (W x H x D):
Weight:
rC eye one s
Diameter without propellers:
Total height:
Propeller diameter:
Take-off weight:
Rechargeable battery:
Admissible flight operation:
Operating conditions:
Admissible temperature range:
Admissible humidity:
Charger
Supply voltage:
Required input current:
Charging current:
2.4 GHz
Auto selection by frequency hopping
max. 40 m (free field)
3 V/DC (2 type micro/AAA batteries)
150 x 100 x 70 mm
130 g
120 mm
47 mm
64 mm
approx. 80 g
1 x LiPo battery (2 x 3.7 V 350 mAh)
Inner and outer area
No to light wind
0 to +40 °C
max. 75% rel. humidity, non-condensing
5 V/DC
min. 1.5 A
500 mA per charging channel
41
