Individual battery cells of a battery pack are usually different. The usb charger has
two separate chargers integrated. Therefore, it is possible that a battery cell is already
charged (led off) and the other battery cell is still being charged (led on). Wait until
both leds have gone out before unplugging the battery.
The plug at the flight battery must be connected in a special manner. Therefore, the flight
battery cannot be charged with conventional liPo chargers. Therefore, use the included
USB charger from the delivery only to charge the flight battery.

8. oPeraTIng eleMenTs of The TransMITTer and rC eye one s

88005rC (mode 1) Transmitter
1. Button on/off
2. Button MODE
3. Control stick right (throttle
and aileron)
4. Aileron trimming
5. Control stick left (elevator
and rudder)
6. Elevator trimming
7. Rudder trimming
8. ACRO button
