Technical specification
Inputs
Outputs
EXT KEY Inputs
SOLO BUS Input
SOLO BUS Output
Performance
Compress or
Gate
Filter
Terminations
Square ONE Dynamics
Eight
Type
Impedance
Maximum input level
Common mode rejection
Eight
Type
Minimum load impedance
Source impedance
Maximum output level
Eight
Type
Impedance
Maximum input level
Common mode rejection
One
Type
Input impedance
Maximum input level
Common mode rejection
One
Type
Output impedance
Maximum input level
Signal drive capability
Output balancing
Frequency response
Dynamic range
Noise floor
Threshold
Ratio
Attack
Release
Gain
Operating modes
Threshold
Range
Attack
Release
Hold
Side chain filter
Audio
Power
39
Technische Daten
Analogue, electronically balanced female XLRs (Pin 2
hot)
10k Ohms
+22dBu
Typically, -80dB at 1kHz
Analogue, electronically balanced male XLRs (Pin 2 hot)
2k Ohms
<60 Ohms
+22dBu
Analogue, electronically balanced jack sockets
20k Ohms
+22dBu
Typically -60dB at 1kHz
Analogue, electronically balanced female XLR
20k Ohms
+22dBu
Typically -60dB at 1kHz
Analogue, electronically balanced male XLR
<60 Ohms
+22dBu
<600 Ohms
Typically -40dB at 1kHz
±0.5dBu (input to output), 20Hz to 20kHz
>117dB (22Hz to 22kHz unweighted)
<-95dBu (22Hz to 22kHz unweighted)
-50dBu to +25dBu
Scale infinity to 1:1 with scale markings 5:1 and 2:1
Scale = fast to slow (100µs to 20ms)
Scale = fast to slow (50ms to 2.5s)
Scale = 0dB to +30dB
Four
Scale = -50dB to +25dB
Scale = -infinity to 0dB
Scale = fast to slow (10µs to 10ms)
Scale = fast to slow (2ms to 2s)
Scale = 2ms to 2s
Scale = 40Hz to 16kHz
3-pin XLRs (male and female) and 1/4" TRS balanced
jack sockets
3-pin IEC
