1.3 Addressing the Microphone Units
Before the system is set up, the microphone units have to be addressed via DIP-switches on the bottom according to the following table.
ON
1 2 3 4 5 6
The DIP-switch 6 has no function.
Microphones
1 - 32
Line 1
Note:
At the factory the microphone unit 1 has been configured as a chairman microphone unit. Using the MCS-Editor another microphone unit can be
chosen as a chairman microphone unit.
Furthermore, make sure that there are not two microphone units having the same address within the same line. For assistance use the MCS-Editor
(refer to chapter 6.8 "Status Check").
Important:
The chairman microphone unit has to be defined again with the MCS-Editor, when there is a reset necessary (user or manufacturer specific).
32
1 = DIP-switch in ON position = switched on
0 = DIP-switch in a number position = switched off
Microphones DIP-switch
33 - 64 1
Line 2
(only MCS 50/64)
1 33 0
2 34 1
3 35 0
4 36 1
5 37 0
6 38 1
7 39 0
8 40 1
9 41 0
10 42 1
11 43 0
12 44 1
13 45 0
14 46 1
15 47 0
16 48 1
17 49 0
18 50 1
19 51 0
20 52 1
21 53 0
22 54 1
23 55 0
24 56 1
25 57 0
26 58 1
27 59 0
28 60 1
29 61 0
30 62 1
31 63 0
32 64 1
DIP-switch DIP-switch DIP-switch
2 3
0 0
0 0
1 0
1 0
0 1
0 1
1 1
1 1
0 0
0 0
1 0
1 0
0 1
0 1
1 1
1 1
0 0
0 0
1 0
1 0
0 1
0 1
1 1
1 1
0 0
0 0
1 0
1 0
0 1
0 1
1 1
1 1
DIP-switch
4 5
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
0 1
0 1
0 1
0 1
0 1
0 1
0 1
0 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
