DISPOSAL
when you are done using your CYBEX OnYX/TOpaz a proper disposal is important.
garbage disposal can be different in every country. please contact your local
waste management company to make sure you are taking the right steps to
dispose of the CYBEX OnYX/TOpaz. always follow the disposal regulations of your
country.
III. INSTRUCTIONS FOR USE
impOrTanT: rEad ThEsE insTruCTiOns CarEfullY BEfOrE
usE and kEEp ThEm fOr fuTurE rEfErEnCE. YOur ChildrEn's
safETY maY BE affECTEd if YOu dO nOT fOllOw ThEsE
insTruCTiOns.
ONYx/TOPAz ASSEMBLY INSTRUCTION
Delivery Status
1. OPENING THE STROLLER
a) Release the folding lock lever.
b) Open the stroller.
c) Push the pedal button down until the locking system is engaged.
2. ASSEMBLING THE HANDLES
aTTEnTiOn: ThE pins On BOTh sidEs musT BE EngagEd.
3. ASSEMBLING THE FRONT WHEELS
–
fit the front wheels to the end of the frame until they engage with a "click".
4. ASSEMBLING THE REAR WHEELS
aTTEnTiOn: ThE whEEl sYsTEm wiTh ThE BrakE pEdal musT
BE fITTED TO THE RIGHT SIDE Of THE BuGGY (VIEWED fROm
BEHInD THE BuGGY).
aTTEnTiOn: ThE pins On BOTh sidEs musT BE EngagEd.
EnsurE ThE BOwdEn CaBlE is insErTEd inTO ThE Clips On
BOTh sidEs.
5. ATTACHING THE BUMPER BAR
a) Slide in latches on left and right side into gadgets sewn into the seat fabric.
b) Press the buttons on left and right side of the bumper bar to take it off.
6. FOLDING THE STROLLER
remove all contents from the basket. Close the canopy. remove the bumperbar.
a) Push forward the primary lock lever underneath the pedal button.
b) Lift the activated primary lock lever to release the stretching system.
10
c) Push down the secondary lock lever (extended bar on the right side of the
locking system).
d) Grip handles and push forward on the stroller to fold it.
e) Press folded stroller until the fold lock is engaged. Its recommended to fasten
the harness before folding the stroller.
7. OPENING THE STROLLER
a) Release the fold lock lever.
b) Open the stroller
c) Push the pedal button down until the locking system is engaged.
warning: EnsurE ThaT all lOCking dEviCEs arE EngagEd
BEfOrE usE.
8. USING THE BRAKES
a) Engage Brake
b) Release Brake
9. automatic front wheel swivel locks – lock – unlock
a) Push the front Swivel Lock Lever until it "clicks". It can be activated in any wheel
positions. The swivel lock will engage automatically when it reaches the right
position.
b) Lift the front Swivel Lock Lever up again to release the Swivel Lock.

10. ExTENDABLE CANOPY

–
attach the canopy adaptor on to the inside of the frame tubes of the buggy.
–
To remove the canopy reverse procedure.
–
Extend the canopy and place canopy rear flap behind the seat.
–
Lie-flat position: Put the rear flap over the seat's back rest and fixate it with the
two velcros underneath.
–
The canopy is adjustable to various positions. The Canopy has a height
adjustment and a forward rotation function. To rotate open the zip located at
the top of the canopy.
The canopy has a fully ratcheting function to create complete coverage. simply
pull on the front of the canopy to the desired position. The height can be easily
adjusted by simply sliding the canopy up or down the frame. The entire canopy
can also be tilted forward. for maximum coverage, unzip the extra panel on top
of canopy and pull forward.
–
The canopy flap at the rear of the stroller can be rolled up and fixed with a
velcro fastener, if required.
11. USING THE HARNESS SYSTEM
a) To fasten the harness system insert left and right side fasteners into the central
harness buckle.
b) To tighten the belts pull the strap on the front of the central harness buckle.
c) To release the belt system press the release button located on the seat in front
of the belt lock while pulling at the shoulder belts.
