Hypertherm MAX200 Betriebsanleitung Seite 141

Maschinenbrenner-Pakete (fortz.)
Siehe Abbildung 6-10
Position Teilenummer
028773
1 023515
2 024260
3 024259
4 023052
5 023052
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
028599
1 023622
2 024319
3 024318
4 023262
5 023262
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
Anmerkung: Hypertherm empfiehlt nicht den Einsatz von Brennerleitungen von mehr als 23 m Länge.
Leitungen von 30,5 m, 38 m und 46 m Länge verursachen Probleme beim Starten.
028781
1 023808
2 024416
3 024413
4 023805
5 023805
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
MAX200 (Maschinenbrenner) Betriebsanleitung
Beschreibung
Shield Torch Lead, 60 Ft.
Lead Pilot, Shield Gas, 60 Ft. (blue)
Lead, Plasma Gas, 60 Ft. (red)
Lead, Cap Sensor, 60 Ft. (gray)
Cable, Water Cooled, 60 Ft. (blue- red band)
Cable, Water Cooled, 60 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4"
Shield Torch Lead, 75 Ft.
Lead Pilot, Shield Gas, 75 Ft. (blue)
Lead, Plasma Gas, 75 Ft. (red)
Lead, Cap Sensor, 75 Ft. (gray)
Cable, Water Cooled, 75 Ft. (blue- red band)
Cable, Water Cooled, 75 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4
Shield Torch Lead, 100 Ft.
Lead Pilot, Shield Gas, 100 Ft. (blue)
Lead, Plasma Gas, 100 Ft. (red)
Lead, Cap Sensor, 100 Ft. (gray)
Cable, Water Cooled, 100 Ft. (blue- red band)
Cable, Water Cooled, 100 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4
STANDARD-KOMPONENTEN
Menge
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6-27
15
