Hypertherm MAX200 Betriebsanleitung Seite 139

Maschinenbrenner-Pakete (fortz.)
Siehe Abbildung 6-10
Position Teilenummer
028383
1 023326
2 024194
3 024192
4 023013
5 023013
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
028457
1 023432
2 024229
3 024224
4 023014
5 023014
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
028458
1 023433
2 024218
3 024225
4 023015
5 023015
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
MAX200 (Maschinenbrenner) Betriebsanleitung
Beschreibung
Shield Torch Lead, 25 Ft.
Lead Pilot, Shield Gas, 25 Ft. (blue)
Lead, Plasma Gas, 25 Ft. (red)
Lead, Cap Sensor, 25 Ft. (gray)
Cable, Water Cooled, 25 Ft. (blue- red band)
Cable, Water Cooled, 25 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4"
Shield Torch Lead, 30 Ft.
Lead Pilot, Shield Gas, 30 Ft. (blue)
Lead, Plasma Gas, 30 Ft. (red)
Lead, Cap Sensor, 30 Ft. (gray)
Cable, Water Cooled, 30 Ft. (blue- red band)
Cable, Water Cooled, 30 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4
Shield Torch Lead, 35 Ft.
Lead Pilot, Shield Gas, 35 Ft. (blue)
Lead, Plasma Gas, 35 Ft. (red)
Lead, Cap Sensor, 35 Ft. (gray)
Cable, Water Cooled, 35 Ft. (blue- red band)
Cable, Water Cooled, 35 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4
STANDARD-KOMPONENTEN
Menge
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6-25
15
