Maschinenbrenner-Pakete - Hypertherm MAX200 Betriebsanleitung

STANDARD-KOMPONENTEN

Maschinenbrenner-Pakete

Siehe Abbildung 6-10
Position Teilenummer
028454
1 023429
2 024216
3 024221
4 023032
5 023032
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
028455
1 023430
2 024217
3 024222
4 023034
5 023034
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
028456
1 023431
2 024228
3 024223
4 023012
5 023012
6 020536
7 046026
8 046061
9 027015
10 004080
11 015090
6-24
15
Beschreibung
Shield Torch Lead, 10 Ft.
Lead Pilot, Shield Gas, 10 Ft. (blue)
Lead, Plasma Gas, 10 Ft. (red)
Lead, Cap Sensor, 10 Ft. (gray)
Cable, Water Cooled, 10 Ft. (blue- red band)
Cable, Water Cooled, 10 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4"
Shield Torch Lead, 15 Ft.
Lead Pilot, Shield Gas, 15 Ft. (blue)
Lead, Plasma Gas, 15 Ft. (red)
Lead, Cap Sensor, 15 Ft. (gray)
Cable, Water Cooled, 15 Ft. (blue- red band)
Cable, Water Cooled, 15 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4
Shield Torch Lead, 20 Ft.
Lead Pilot, Shield Gas, 20 Ft. (blue)
Lead, Plasma Gas, 20 Ft. (red)
Lead, Cap Sensor, 20 Ft. (gray)
Cable, Water Cooled, 20 Ft. (blue- red band)
Cable, Water Cooled, 20 Ft. (blue- green band)
Lead Insulator, 9/16" ID x 2-1/2"
Tubing, 1-1/2" ID Shrink Black
2" ID Tinned Braid
Ring Compress, Shield Torch Lead
Collar, Shield Torch Leads
Clamp, Hose, 1-5/16 - 2-1/4
MAX200 (Maschinenbrenner) Betriebsanleitung
