STANDARD-KOMPONENTEN

Empfohlene ersatzteile

Stromquelle

Teilenummer
005044
005121
005122
005088
005168
005089
009604
027080
027079
027080
041151*
041186*
041143
005102
006014
005093
129118
009384
009385
041534
008322
008317
003021
005130
029317
029202
006045
027005
011025
011031
011027
029325
029323
029326
029361
028872
028873
* Stromquellen mit THC
6-16
15
Beschreibung
Switch, toggle SPDT
Pushbutton, green, illmn.
Pushbutton, red, extended
Holder, lamp
Bulb, 28VDC
Lens, white
Resistor, variable, 100 K, 1 turn
Fan, 225 CFM, 120 VAC, 50/60 Hz
Fan, 450-550 CFM, 120 VAC, 50/60 Hz
Fan, 225 CFM, 120 VAC, 50/60 Hz
PCB, THC motherboard
PCB, SA-THC
PCB, Control
Thermostat, 160°C, 6 Amp
Valve, solenoid
Switch, pressure, 0-90 psi
Chopper SA, CH130 CE/LVD
Diode, 85 Amp, 1000V, fwd polarity
Diode, 85 Amp, 1000V, rev polarity
PCB, power distribution
Fuse, Amp., 250 VAC
Fuse, semiconductor, 125 Amp, 250 V
Relay, 120 VAC
Switch, pressure, SPDT, 0-15 psi
Transformer, High Voltage SA
Sensor, current
Valve, solenoid, coolant return
Filter, coolant, deionizing
Filter/regulator
Filter Element (used with 011025)
Gauge, high pressure
Coolant Pump SA
Switch, water temperature, 162°F
Switch, level
Switch, flow, 0.5 gpm
Coolant, propylene glycol 30%/
deionized water 70% (standard mixture)
Coolant, propylene glycol 100%
MAX200 (Maschinenbrenner) Betriebsanleitung
Kennzeichnung
S1
PB1
PB2
-
-
-
R9
M2
M4
M3
PCB10
PCB9
PCB7
TS1
V1
PS1
CH1/CH2
D1, D2, D3
D4, D5, D6
PCB6
-
F3, F4
CR1
PS3
T5
CS1
V8
-
FR1
-
-
TS2
LS1
FS1
