Hypertherm MAX200 Betriebsanleitung Seite 129

Position Teilenummer Beschreibung
129252
1 128385
2 128384
3 031122
129383
4 006046
029361
5 005119
6 006053
7 027136
8 027139
9 027005
10 011025
11 011027
12 002304
13 022036
14 129618
15 029323
16 006099
MAX200 (Maschinenbrenner) Betriebsanleitung
Pump Motor Subassembly
Kit, Replacement Motor, 1/3 HP
Kit, Replacement Pump, 70 GPH
Drive Coupling, Pump to motor
Valve Subassembly (w/ elec connectors)
Valve, Sol 240V 3/8 NPT NC
Flowswitch Subassembly (w/ elec connector)
Flowswitch, 0.5 GPM
Valve, Check 1/3 PSI, 1/4 NPTM
Heat Exchanger, Water/Air
Filter Housing, 10" X 3/8 NPT
Filter, Element
Filter Regulator
Gauge, High Press (for 011025)
Reservoir, coolant
Gauge, liquid level
Level Switch Subassembly, 1/2 NPT
Temp Switch Subassembly, 162 Deg F
Bib drain valve 1/4 NPT
STANDARD-KOMPONENTEN
Kennzeichnung
M1
V7
FS1
MX1
LS1
TS2
Menge
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6-15
15
