AUDIO SETTINGS
EQ SETTING
EQ PRESET Select a preset equalizer suitable to the music genre. (Select [USER] to use the
settings made in [EASY EQ].)
FLAT ( default) / HARD ROCK / HIP HOP / JAZZ / POP / R&B / TALK / USER /
VOCAL BOOST / BASS BOOST / CLASSICAL / DANCE
EASY EQ Adjust your own sound settings. The settings are stored to [USER].
SUB.W SP * *
1 2
: 00 to +06
SUB.W * *
1 3
: –08 to +08
BASS LVL: –06 to +06
MID LVL: –06 to +06
TRE LVL: –06 to +06
1 BASS / MIDDLE / TREBLE: Select a sound tone.
PRO EQ
2 Adjust the sound elements of the selected sound tone.
BASS Frequency: 60/ 80/ 100/ 200 HZ
Level:
Q:
MIDDLE Frequency: 0.5/ 1.0/ 1.5/ 2.5 KHZ
Level:
Q:
TREBLE Frequency: 10.0/ 12.5/ 15.0/ 17.5 KHZ (Default: 10.0 KHZ
Level:
Q:
AUDIO
BASS BOOST +01 to +05 (+01): Selects your preferred bass boost level. ; OFF: Cancels.
LOUD 01 / 02: Boosts low or high frequencies to produce a well-balanced sound at
low volume. ; OFF: Cancels.
12
Default: XX
(Default: 03
00
00
00
00)
( Default: 80 HZ
–06 to +06
Q1.0/ Q1.25/ Q1.5/ Q2.0
(Default: 1.0 KHZ
–06 to +06
Q0.75/ Q1.0/ Q1.25
–06 to +06
Q FIX
SUB.W LEVEL * 1 SPK-OUT *
PRE-OUT *
SUB.W *
3
ON / OFF: Turns on or off the subwoofer output.
SUB.W LPF * 1
THROUGH: All signals are sent to the subwoofer. ; LOW 55HZ /
MID 85HZ / HIGH 120HZ: Audio signals with frequencies lower than
55 Hz/ 85 Hz/ 120 Hz are sent to the subwoofer.
SUB.W PHASE * 1
REVERSE (180°)/ NORMAL (0°): Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
(Selectable only if a setting other than [THROUGH] is selected for
[SUB.W LPF].)
FADER R06 to F06 (00): Adjusts the front and rear speaker output balance.
BALANCE * 4
L06 to R06 (00): Adjusts the left and right speaker output balance.
00
VOL ADJUST –15 to +06 (00): Preset the initial volume level of each source
Q1.0)
(compared to the FM volume level). Before adjustment, select the
source you want to adjust. ("VOL ADJ FIX" appears if FM is selected.)
00
Q1.25)
AMP GAIN LOW POWER: Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50 W to prevent damaging
00
the speakers.) ; HIGH POWER: The maximum volume level is 35.
Q FIX)
D.T.EXP ON: Creates realistic sound by compensating the high-frequency
(Digital Track components and restoring the rise-time of the waveform that are lost in
Expander) audio data compression. ; OFF: Cancels.
*
1
Displayed only when [SUB.W] is set to [ON].
*
2
Displayed only when [SPK/PRE OUT] is set to [SUB.W/SUB.W]. ( 13)
* 3
Displayed only when [SPK/PRE OUT] is set to [REAR/SUB.W] or [SUB.W/SUB.W]. ( 13)
* 4
This adjustment will not affect the subwoofer output.
2
00 to +06 (+03): Adjusts the output level of the
subwoofer connected via speaker lead. ( 21)
3
–08 to +08 (00): Adjusts the output level of the
subwoofer connected to the lineout terminals (REAR/
SW) through an external amplifier. ( 21)
