Miscellaneous
Dimensions (LxWxH) in mm ............................................. 151x62x40,5 mm
Weight ............................................................................... Approx. 360 g
Bus data
Transfer protocol ............................................................... Ethernet/IP
Transfer rates .................................................................... 10/100
Electrical isolation ............................................................. 500 V between bus and internal logic
ODVA Vendor ID ............................................................... 640 Dec
Power supply
Operation voltage U
and Sensor power supply 24VIN .... 24 V DC (must always be connected)
S
Actuator power supply 24V ................................................ 24 V DC
Current per PIN ................................................................. Max 8A
Operation voltage range ................................................... 18 ... 30 V DC
Current consumption ......................................................... ≤ 200 mA
Sensor supply .................................................................... 24 V DC (not switchable)
Operating voltage range sensor supply ............................. 18 ... 30 V DC
Actuator supply .................................................................. 24 V DC (switchable)
Operating voltage range actuator supply ........................... 18 ... 30 V DC
Reverse voltage protection modul electronics ................... yes
Reverse voltage protection sensor supply ......................... yes
Reverse voltage protection actuator supply ...................... yes
Overvoltage protection ....................................................... yes (suppressor diode)
International system connection
Rated current sensor supply ............................................. 4 A for each module plug-in location
Rated current actuator supply ........................................... 4 A for each module plug-in location
Overload/short-circuit ......................................................... electronic short-circuit recognition
........................................................................................... time of liberation < 10 ms
MBit/s,
IEEE
Negotiation, half- or full Duplex by 10 and
100 Mbit/s available, automatically settings
Cube67+ | BN-E/IP
802.3,
Auto-
71
