Part List - Energetics ET 610 Gebrauchsanweisung

Partlist
No. Description
1 Main frame
2 Front stabilizer
3 Hex bolt M8*1.25*95L
4 Adjustable foot cap
5L Left rolling foot cap
5R Right rolling foot cap
6 Curve washer D22*D8.5*1.5T
7 Spring washer D15.4*D8.2*2T
8 Domed nut M8*1.25*15L
9 Hex bolt M8*1.25*20L
10 Handle bar post
11 Supporting tube for pedal
12 Supporting tube for moveable
handlebar
13 Bushing D35*11L
14 Bushing D19.15
15 Half ball cap
16 Bearing #99502
17 Allen hex bolt M8*1.25*100L
18 Nylon nut M8*1.25*8T
19 Rear stabilizer
20 Square neck bolt M6*1*45L
21L Left pedal
21R Right pedal
22 Round screw ST4*1.41*10L
23A Upper foot cover (right)
23B Upper foot cover (left)
24 Anti-loose nut
25 Pin
26 C-ring D22.5*D18.5*1.2T
27 Sensor cable
28 Electrical cable
29 Upper computer cable
30 Lower computer cable
31 Flat washer D14*D6.5*0.8T
32 C-ring D21.5*D17.5*1.2T
33 Crank
34 Cross screw
35 Belt
36L Left chain cover
36R Right chain cover
37 Flywheel
38a Upper protect cover
38b Lower protect cover
39 Side cover
40 Hex bolt M8*1.25*20
41 Bolt M8*52
Qty No. Description
1 42 Round cover
1 43 Bearing #6004-2RS
4 44 Flat washer D20*D11*2.0T
2 45 Nylon nut M8*1.25*8T
1 46 Flat washer D28*D8.5*3T
1 47 Wave washer D21*D16*0.3T
20 48 Flat washer D24*D16*1.5T
14 49 Upper protective cover
4 50 Fixing plate for the magnet
8 51 Ladder bolt M10*1.5*58L
1 52L Left moveable handlebar
2 52R Right moveable handlebar
2 53 Foam 680L
4 54 Foam 530L
8 55 Mushroom cap
2 56 Spring
2 57 Flat washer D24*D13.5*2.5T
2 58 Hex bolt M6*1.0*15L
2 59 Hex bolt M8*1.25*50L
1 60 Wave washer D26*D19.5*0.3T
4 61 Crank axle
1 62 Round magnet
1 63 Cross screw ST3.5*1.27*15L
2 64 Computer UM6609L2-7
2 65 Handle pulse
2 Handle pulse cable
2 66 Flat washer D21*D8.5*1.5T
6 67 Front computer base
2 68 Rear computer base
1 69 Front pedal axle
1 70 Fixing plate for the idle wheel
1 71 Plastic flat washer
1 72L Left handle bar
16 72R Right handle bar
8 73 Flat washer D14*D6.5*0.8T
2 74 Front left foot cover
10 75 Front right foot cover
1 76 Plastic cover
1 77 Knob
1 78 Spring
1 79 Nylon nut
2 80 Buffer
2 81 Inner tube
2 82 Nylon nut M10*1.5*10T
2 83 Allen hex bolt M8*1.25*30L
1 84 C-ring S-16 (1T)
17
Qty
2
2
2
2
1
3
1
1
1
2
1
1
2
2
2
1
2
16
1
4
1
1
8
1
2
2
2
1
1
2
1
1
1
1
4
2
2
2
4
1
1
4
1
2
1
3
