6. Einige Hinweise zur Pflege von
Mikrophonen
Staubschutz verwenden: Mikrophone, die nicht im Ein-
satz sind, sollte man nicht auf dem Stativ einstauben
lassen. Mit einem Staubschutzbeutel (nicht fusselnd)
wird dies verhindert. Wird ein Mikrophon längere Zeit
nicht verwendet, sollte es in einem Schrank bei nor-
malem Umgebungsklima aufbewahrt werden.
Popschutz verwenden: Ein Popschutz hat nicht nur die
Aufgabe, bei Gesangsaufnahmen die Entstehung von
Poplauten zu verhindern. Er vermeidet auch effizient,
daß sich von der Feuchtigkeit des Atems bis hin zu
Essensresten unerwünschte Partikel auf der Membran
ablagern.
Keine überalterten Windschutze verwenden: Auch
Schaumstoff altert. Das Material kann brüchig und krü-
melig werden. Anstatt das Mikrophon zu schützen,
kann er dann zur Verunreinigung der Mikrophonkap-
sel führen. Überalterte Windschutze also bitte ent-
sorgen.
Funktionstest: Moderne Kondensatormikrophone neh-
men durch lautes Ansprechen keinen Schaden. Zur
Kontrolle, ob ein solches Mikrophon angeschlossen ist,
sollte man es aber keinesfalls anpusten oder anpop-
pen, da dies einem akustischen Signal von mehr als
140 dB (!) entsprechen kann. Normale Sprache ge-
nügt zum Funktionstest völlig.
Selbsthilfe kann teuer sein! Leider kommt es doch
vor, daß durch eine Selbstreparatur mehr beschädigt
als behoben wird. Insbesondere das Reinigen ver-
schmutzter Kapseln erfordert viel Erfahrung und die
Hand eines Fachmanns. Der Lackschutz auf Platinen
zeigt u.a. an, daß dort nicht gelötet werden darf. Eini-
ge Bauteile sind speziell selektiert und können nicht
durch Material von der Stange ersetzt werden. Um
unnötige Kosten zu vermeiden, empfiehlt sich die Ein-
sendung an unsere Vertretungen oder an uns.
Inspektion durchführen lassen: Regelmäßiges Durch-
checken des Mikrophonbestands, wie es einige Schau-
spielhäuser und Rundfunkanstalten praktizieren, kann
bei der Früherkennung von Schäden helfen. Leichte
Verschmutzungen lassen sich eher beseitigen, als eine
untrennbar in die Membran eingebrannte Nikotin-
schicht. Insbesondere bei Mikrophonen im Verleih und
in verunreinigenden Umgebungen empfiehlt sich die
regelmäßige Kontrolle, deren Kosten im Vergleich zu
einer aufwendigen Reparatur sehr gering sind.
6. Some Remarks on Microphone
Maintenance
Use the dust cover: Microphones not in operation
should not be left on the floor stand unprotected. With
a non-fluffy dust cover the microphone can be pro-
tected from dust settling on the capsule. When not
in use for a longer spell, the microphone should be
stored in a closet at standard climatic conditions.
Use a pop screen: The pop screen not only elimi-
nates the plosive pop noises in vocal recordings. In
close-miked vocal applications it also efficiently pro-
tects the diaphragm from almost anything, including
breath humidity down to food particles.
Do not use overaged wind shields: Even the foam
material of wind shields ages. With very old wind
shields, the material decays and becomes brittle. The
particles can then settle on the diaphragm. So, please
dispose of overaged wind shields.
Function testing: Modern condenser microphones can-
not be harmed by very high sound pressure levels.
Still, there is no need for pop-testing to see if a mi-
crophone is working and pulled up on the console.
Normal speech is good enough, and pop-testing can
produce sound pressure levels exceeding 140 dB!
Do-it-yourself can be expensive: Do-it-yourself repairs
can sometimes be more harmful than beneficial. Es-
pecially cleaning soiled capsules does take a skilled
hand and quite some experience. Furthermore, the
protective lacquer shows the parts of the printed cir-
cuit boards where e.g. soldering should be avoided.
Other parts may be specifically selected and cannot
be replaced by standard components. To avoid un-
necessary cost, we recommend sending in defective
microphones to our distributors, or to us directly, for
servicing.
Regular servicing: As some theaters and broadcasters
do on a regular basis, sending in microphones for serv-
icing can help in early recognition of damages. Slight
soiling can be removed much easier than some nico-
tine layer firmly embedded in the diaphragm. Espe-
cially with microphones on loan and in dustier/ smok-
ier environments regular checking proves beneficial,
as the cost is rather small compared to a major over-
haul.
12
7. Zubehör
Weitere Artikel sind im Katalog „Zubehör" beschrieben.
7.1 Tisch- und Fußbodenständer
MF 3 ........................................ sw ............................. Best.-Nr. 07321
MF 3
MF 3
MF 3
MF 3
Der Mikrophonfuß MF 3 ist ein Tischständer mit Eisen-
fuß, 1,6 kg schwer, Durchmesser 110 mm. Der Stän-
der ist schwarzmatt lackiert und steht gleitfest auf einer
Moosgummischeibe. Ein umwendbarer Gewindezapfen
und ein mitgeliefertes Reduzierstück ermöglichen die
Verwendung für 1/2"- und 3/8"-Gewindeanschlüsse.
MF 4
MF 4
MF 4
MF 4 ........................................ sw ............................. Best.-Nr. 07337
MF 4
Der Mikrophonfuß MF 4 ist ein Fußbodenständer aus
Grauguß, ca. 2,6 kg schwer, Durchmesser 160 mm. Der
Ständer ist schwarzmatt lackiert und steht gleitfest auf ei-
nem Gummiring. Ein umwendbarer Gewindezapfen und
ein mitgeliefertes Reduzierstück ermöglichen die Verwen-
dung für 1/2"- und 3/8"-Gewindeanschlüsse.
7.2 Stativverlängerungen
Die Stativverlängerungen STV... werden zwischen Fuß-
bodenständer und Mikrophonhalterung geschraubt. Da-
durch entstehen unterschiedlich hohe Tisch- oder Fuß-
bodenstative.
Die STV... haben eine Länge von 40, 200, 400 oder
600 mm. Durchmesser: 19 mm.
STV 4 4 4 4 4 ...................................... sw ............................. Best.-Nr. 06190
STV
STV
STV
STV
STV 20
STV
STV
STV
STV
20
20 ................................... sw ............................. Best.-Nr. 06187
20
20
STV 40
STV
STV
40
40
40 ................................... sw ............................. Best.-Nr. 06188
STV
STV
40
STV 60
STV
STV
STV
STV
60
60
60 ................................... sw ............................. Best.-Nr. 06189
60
7.3 Elastische Aufhängung
Um mechanische Erschütterung fernzuhalten, emp-
fiehlt sich die Verwendung einer elastischen Mikro-
phonaufhängung.
EA 170
EA
EA
EA
EA
170
170
170 ................................. ni ............................... Best.-Nr. 07271
170
EA
EA
EA
EA
EA 170
170 mt
170
170
170
mt ......................... sw ............................. Best.-Nr. 07273
mt
mt
mt
(gehört zum Lieferumfang)
Die EA 170 ist für die Mikrophone TLM 170 (R) und
M 149 Tube vorgesehen. Der schwenkbare Gewinde-
anschluß zur Befestigung auf Stativen hat 5/8"-27-Gang.
Ein Reduzierstück zur Verbindung mit 1/2"- und 3/8"-
Gewindezapfen wird mitgeliefert.

7. Accessories

Further articles are described in the catalog "Accessories".
7.1 Table and Floor Stands
MF 3 ........................................ blk .............................. Cat. No. 07321
MF 3
MF 3
MF 3
MF 3
Table stand with iron base, 1.6 kg, 110 mm in diam-
eter. The table stand has a matt black finish and rests
on a nonskid rubber disk attached to the bottom. A
reversible stud and a reducer for 1/2" and 3/8" threads
are also supplied.
MF 4 ....................................... blk .............................. Cat. No. 07337
MF 4
MF 4
MF 4
MF 4
Floor stand with grey cast iron base, 2.6 kg, 160 mm
in diameter. The floor stand has a matt black finish and
rests on a nonskid rubber disk attached to the bottom.
A reversible stud and a reducer for 1/2" and 3/8" threads
are also supplied.
7.2 Stand Extensions
The STV... stand extensions are used between mi-
crophone and floor stands to provide table or floor
stands of variable heights.
The STVs are 40, 200, 400 or 600 mm long. Diame-
ter: 19 mm.
STV 4 4 4 4 4 ...................................... blk .............................. Cat. No. 06190
STV
STV
STV
STV
STV 20
STV
STV
STV
STV
20
20
20
20 ................................... blk .............................. Cat. No. 06187
STV
STV
STV 40
STV
STV
40
40
40
40 ................................... blk .............................. Cat. No. 06188
STV
STV
STV 60
60
60
60 ................................... blk .............................. Cat. No. 06189
STV
STV
60
7.3 Elastic Suspension
The use of an elastic suspension is recommended to
prevent the microphone from being exposed to strong
mechanical vibrations caused by structure borne shock
waves.
EA 170
EA
EA
170 ................................. ni ................................ Cat. No. 07271
170
170
EA
EA
170
EA
EA
EA 170
EA
EA
170
170
170
170 mt
mt ......................... blk .............................. Cat. No. 07273
mt
mt
mt
(included in the supply schedule)
The EA 170 is designed for the TLM 170 (R) and
M 149 Tube microphones. It has a swivel mount with
a 5/8"-27 female thread that can be fastened to tri-
pods. Included is a threaded adapter to connect to
1/2"- and 3/8" studs.
