Zum Schutz des Mikrophons bei Nahbesprechung wird
die Verwendung eines Popschutzes empfohlen:
• Popschutz PS 20.
Nähere Angaben dazu im Kapitel „Zubehör".
2.3 Ausführungsform und Beschaltung des
Mikrophon- und Netzgeräteausgangs
Das Mikrophon hat eine nickelmatte Oberfläche. Der
8-polige Stecker des Mikrophons und des Netzgerä-
tes ist folgendermaßen beschaltet:
Pin 1: –70 V
Pin 2: +5 V
Pin 3: Modulation (+ Phase)
Pin 4: +70 V
Pin 5: Sensorleitung
Pin 6: Masse
Pin 7: +32 V
Pin 8: Modulation (– Phase)
Das zum Lieferumfang gehörende 8-polige Kabel verbin-
det das Mikrophon mit dem Netzgerät N 149 A.
Die Modulation liegt hier an einem 3-poligen XLR-Stecker.
Erforderliches Gegenstück: XLR 3 F. Die Zuordnung der
Mikrophonanschlüsse entspricht DIN 45 599, Kennzei-
chen „I" bzw. IEC 268-12 (pin. conn. 130-x-IEC 02).
Bei einem Schalldruckanstieg vor der vorderen Mikro-
phonmembran tritt an Stift 2 eine positive Spannung
auf.
2.4 Mikrophonkabel
Die akustischen Eigenschaften der Mikrophone wer-
den auch durch sehr lange (Neumann-) Kabel nicht
beeinflußt. Erst bei Kabellängen deutlich über 300 m
macht sich ein Abfall im oberen Frequenzbereich be-
merkbar.
Neumann bietet ein vielfältiges Kabelsortiment an, von
dem hier ein Ausschnitt erwähnt wird. Andere als
die genannten Kabellängen sowie Kabelmaterial ohne
Armaturen sind auf Wunsch lieferbar.
Für das M 149 Tube stehen folgende Kabel zur Ver-
fügung:
To protect the microphone in close miking applica-
tions we recommend using a popscreen:
• PS 20 Popscreen.
For details, see the topic "Accessories".
2.3 Type and Configuration of the
Microphone and Power Supply Outputs
The microphone is finished in matt nickel. The 8-pin
connector of the microphone and the corresponding
connector of the power supply unit have the follow-
ing configuration:
Pin 1: –70 V
Pin 2: +5 V
Pin 3: audio signal (+ phase)
Pin 4: +70 V
Pin 5: sensor line
Pin 6: ground
Pin 7: +32 V
Pin 8: audio signal (– phase)
The included eight-core cable connects the micro-
phone to the N 149 A power supply unit.
At the power supply unit, the audio signal is available
at a 3-pin XLR socket which requires an XLR-3F ca-
ble. The pin assignment corresponds to DIN 45 599,
part "I" and IEC 268-12 (pin. conn. 130-x-IEC 02), re-
spectively.
An increase in sound pressure at the microphone's
front diaphragm produces a positive voltage at pin 2.

2.4 Microphone Cables

The electroacoustic properties of the microphones are
not affected even by very long (Neumann) cables.
However, if cables are well over 300 m, a fall-off in
the upper frequency range becomes apparent.
Neumann offers a wide range of cables. Only a selec-
tion is presented here. Other cable lengths or cable
materials without connectors are available on request.
The following cables are available for the M 149 Tube:
6
KT 8 ........................................ sw ............................. Best.-Nr. 08407
KT 8
KT 8
KT 8
KT 8
(gehört zum Lieferumfang)
10 m langes Mikrophonkabel mit 8-poligen DIN 45326-
Steckverbindern. Verbindet das Mikrophon mit dem
Netzgerät N 149 A.
IC 3 mt
IC 3 mt
IC 3 mt ................................. sw ............................. Best.-Nr. 06543
IC 3 mt
IC 3 mt
10 m langes Mikrophonkabel, Durchmesser 5 mm, mit
Doppeldrallumspinnung als Abschirmung. Schwarz-matte
3-polige XLR-Steckverbinder. Führt am Ausgang des
Netzgerätes die Modulation weiter.
AC
AC
25
25
AC 25
AC
AC
25
25 (0,3 m) ....................................................... Best.-Nr. 06600
Adapterkabel mit einer 3-poligen XLR-Buchse und ei-
nem 6,3 mm Monoklinkenstecker, unsymmetrisch, für
den Anschluß des 3-poligen XLR-Ausganges eines Spei-
segerätes BS 48 i oder N 48 i-2 an Geräte mit 6,3 mm
Monoklinkenbuchse.
KT 8 ........................................ blk .............................. Cat. No. 08407
KT 8
KT 8
KT 8
KT 8
(included in the supply schedule)
10 m microphone cable with 8-pin DIN 45326 con-
nectors. For connecting the microphone to the
N 149 A power supply unit.
IC 3 mt
IC 3 mt
IC 3 mt ................................. blk .............................. Cat. No. 06543
IC 3 mt
IC 3 mt
10 m long microphone cable, 5 mm in diameter, with
double twist (double helix) braiding as shield. Three-
pin XLR connectors, matt black. For feeding the audio
signal to mixing consoles, etc.
AC
AC
25
25
AC 25
AC
AC
25 (0.3 m) ........................................................ Cat. No. 06600
25
Adapter cable with 3-pin XLR connector and a 6.3 mm
monojack, unbalanced. It is used to connect 3-pin XLR
outputs of the BS 48 i or N 48 i-2 power supplies to
units with a 6.3 mm monojack input.
7
