B-16
Pinbelegungen der E/A-Schnittstellen
100-Pin-Erweiterungsbus (Fortsetzung)
Pin-
Phys.
Nr.
Name
66
/DTACK
67
AD29
68
READ
69
AD28
70
/DS2
71
AD27
72
/DS3
73
Ground
74
/CCS
75
SD0
76
AD26
77
SD1
78
AD25
79
SD2
80
AD24
81
SD3
82
SD7
83
SD4
84
SD6
85
Ground
86
SD5
87
Ground
88
Ground
89
Ground
90
Ground
91
SenseZ3
92
7M
93
DOE
94
/IORST
95
/BCLR
96
/INT1
97
/FCS
98
/DS1
99
Ground
100 Ground
Zorro-II-
Zorro III
Name
Adreßphase
/DTACK
/DTACK
D13
A29
READ
READ
D12
A28
/LDS
/DS2
D11
A27
/UDS
/DS3
Ground
Ground
/AS
/CCS
D0
N/A
D10
A26
D1
N/A
D9
A25
D2
N/A
D8
A24
D3
N/A
D7
N/A
D4
N/A
D8
N/A
Ground
Ground
D5
N/A
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Ground
SenseZ3
E7M
7M
DOE
DOE
/BUSRST
/IORST
/GBG
/BCLR
(/EINT1)
/INT1
No Connect /FCS
No Connect /DS1
Ground
Ground
Ground
Ground
Zorro III
Datenphase
/DTACK
D29
READ
D28
/DS2
D27
/DS3
Ground
/CCS
D16
D26
D17
D25
D18
D24
D19
D23
D20
D22
Ground
D21
Ground
Ground
Ground
Ground
SenseZ3
7M
DOE
/IORST
/BCLR
/INT1
/FCS
/DS1
Ground
Ground
