To integrate the dimming actuator into your Home-
Matic system and enable it to communicate with
other HomeMatic devices (e.g. HomeMatic Window
Contact), you must teach it in first. You can teach-in
the dimming acutator directly to other HomeMatic de-
vices or to the HomeMatic Central Control Unit:

6.2.1 Teaching-in to HomeMatic devices

If you would like to teach-in the dimming acutator to
one or more HomeMatic devices, you must put the
devices to be taught-in into teach-in mode and select
the required teach-in channel. To do this, proceed as
follows:
During teach-in, please make sure you maintain
a distance of at least 50 cm between the
devices.
• Activate the teach-in mode of your dimming actuator.
Therefore, press and hold down the channel button
for at least 4 seconds. The device LED will flash con-
tinuously to indicate that teach-in mode is active. The
teach-in time is 20 seconds.
• Now put the device you wish to teach-in the dim-
ming actuator into teach-in mode. Please follow the
relevant operating manual instructions of the corre-
