selector / FIXTURES 1-16 / the device whose channels you have a strobe
Want to assign.
4. Use the / ◄ / and / ► / buttons to select the desired channel you want to assign to Strobe. The display shows:
eg.
01Yc
DMX Channel 1 - Strobe is active,
or
02No
DMX Channel 2 - Strobe is not assigned.
5. Press the / EDIT / REC / button to assign the channel to Strobe, or press the / DEL / CLR / button to clear the
assignment.
6. Press and hold the / EDIT / REC / button to exit the programming mode
You can adjust the flash rate of the stroboscope at any time by holding down the "Strobe" button and manually
adjusting the / STROBE SPEED / fader.

2.5 Blackout function (dark):

Press the / BLACKOUT / button to turn off all connected headlights. Another push-button
Returns to the previous brightness.

2.6 Reset to factory settings:

Here, the device can be reset to the factory settings.
1. Turn off the unit.
2. While holding down the / EDIT / REC /, / RUN MODE / and / DEL / REC / buttons, turn the unit on. The display
shows:
REST
T
After approx. 2 seconds the device is ready for use.

2.7 USB Connection:

Data can be stored and read via the USB socket (USB stick). The entire memory content (scenes, chases) of the
internal memory is stored as a file. You can create up to 16 backups.

2.7.1 Storing data on the USB stick (Data backup):

The USB stick must be connected to the USB socket.
1. Press the / RUN MODE / and / ◄ / buttons simultaneously. The display shows
SAVE
T
2. Use the number buttons / FIXTURE / to select the memory you want to save.
The display shows, eg:
Fl01
T
