2. PROGRAMMINGOFTHE RECEIVER

2.1. Main menu of the receiver

The receiver has ability to program parameters of work. The structure of the menu of the receiver is presented on the
fig.5. The programming takes place with the help of the LED display, A nad B buttons of the receiver and buttons of any
DTM433MHz series remote control, the best with 4 buttons.After pressingA button on the receiver, main menu appears.
Switching next options takes place with buttons of the remote control.
ATTENTION! The first remote control used after entering main menu of the receiver will be used to move on
the menu in this session.
The way of moving in the menu using different types of remote controls is presented on fig. 3. In case of using 2 button
remote control for moving up it is necessary to press the first and second button of the remote simultaneously.
A button of the receiver is used to confirm, B button of the receiver for coming back in the structure of the menu or
resignation from applied changes.
VICTORY /
ECOVICTORY
NEO
Fig. 3. The way of moving in the menu using
different types of remote controls.
1
2 3 4
NEON
Fig. 4. Display indication of receiver in operating mode.
54
The right dot on the display
indicates the operational mode.
Example:
P1 indicates the use of button no. 1,
in the next cycle the number
of used remote is displayed.
