GENERAL INFORMATION

MAX2 is advanced, four-channel receiver intended for the cooperation with drivers of gates, roller-blinds and other
automation devices where giving steering impulse is required. It allows to extend the functionality of the installation for
the function of the remote control in a very simple manner.

TECHNICAL DATA

Power supply:
Memory of the receiver:
Operational temperature:
Size of external case:
Splash-proofness:
Installation manner:
Weight:
Operation frequency:
Relay outputs:
Operation mode:
Output switch on time in monostable mode: from 0,1s to 6553,5s (about 110min.) with resolution of 0,1s;
Very transparent and simple user interface based on the display, LED diodes and two buttons;
Possibility of remote assigning remote controls without the need to use buttons of the receiver;
Possibility of managing the receiver by theUSB connector;
Possibility of checking the number of assigned remote controls;
Possibility of managing the remote control without its physical presence;
Possibility of copying the memory by using the optional B700 module.
12...24VAC/DC
700 DTM433MHz series remote controls
(MULTI version –also variable KeeLoq® codes of other producers)
from -20°C to +55°C
79x138x33mm
IP-53
outside or in the case of other devices
125g
433MHz
4 NO/NC outputs
monostable, bistable, momentary
