Button for light functions
Sensor 1 x short
10 sec. - 30 min. max. 4 hours.
Sensor mode Permanent light mode
The Sensor Switch basically Button 1 x 'ON'
operates in sensor mode. The connected light is set
The light is switched 'ON' for to permanent light for 4
the preset time in response hours (red LED illuminates).
to movement within the After this period, the Sensor
detection zone. Switch immediately returns
to sensor mode (red LED
'OFF').
Permanent light can be
interrupted before this time
elapses by pressing the
button (red LED 'OFF').
18

Troubleshooting

Malfunction
1 x 3 sec.
Sensor Switch
without power
Sensor Switch
does not switch 'ON'
OFF
Permanent light OFF mode
Press button for 3 sec.
The connected light is
switched 'OFF' (red LED
fl ashes). By briefl y pressing
Sensor Switch
the button again, the Sensor
Switch returns immediately does not switch 'OFF'
to sensor mode (red LED
'OFF').
Sensor Switch
keeps switching 'ON'/'OFF'
Cause Remedy
a a
Fuse blown, Replace fuse;
not switched 'ON' switch 'ON' mains switch,
check wiring with voltage
tester
a
a
Short circuit Check connections
a a
Light bulb burnt out Replace light bulb
a a
Twilight setting in night- Readjust
time mode during day-
light mode
a a
Additional two-way Switch power 'ON'
switch 'OFF'
a a
Fuse blown New fuse,
check connection
if required
a a
Permanent light 'OFF' Switch power 'ON'
mode switched 'ON'
a a
Continued movement Check detection zone
within the detection zone
a
a
Switched 'ON' light is Check detection zone
within detection zone of
IR 180 AP and switches
'ON' again as a result of
temperature change
a
a
Permanent light operation Switch 'OFF' permanent
switched 'ON' light operation
(red LED illuminates)
a a
Other Sensor Switch is Await time setting of the
connected in parallel and other Sensor Switch
still active
a a
Switched 'ON' light is Check detection zone
within IR 180 AP detec-
tion zone
a a
Animals moving in Check detection zone
IR 180 AP detection zone
a a
Curtains, fl owers, etc. Check detection zone
move within the detection
zone of the HF 360 AP
and cause switching
again by motion
19
