Principle
With the IR 180 AP and sensor technology switches
HF 360 AP Sensor the light 'ON' automatically
on entering the detection
Switches, groping for the
light switch is fi nally a thing zone and 'OFF' again after
of the past! The intelligent the preset time. This is not
IR 180 AP:
Angle of coverage: 180°
The IR 180 AP is equipped
with a pyro sensor which
HF 360 AP:
Angle of coverage: 360°
The HF 360 AP is an active
motion detector. It reacts
- independently of tem-
perature - to the slightest
movement. The integrated
14
only extremely convenient,
but also increases safety
and is energy and cost
saving.
detects the invisible heat
emitted by moving objects
(pedestrians, animals etc.).
8 m
The heat thus detected is
max.
electronically converted and
switches on connected con-
sumers (e.g. a light). No heat
radiation is detected through
obstacles, such as walls
or glass and no switching
therefore occurs.
HF sensor transmits high
frequency electromag-
netic waves (5.8 GHz) and
8 m
receives their echo. In re-
max.
sponse to the slightest
movement in the detection
zone, the change in echo
is perceived by the sensor.
A microprocessor subse-
quently triggers almost with-
out delay the switching
command "light ON". De-
tection is possible through
doors, panes of glass or
thin walls.
Technical specifi cations
IR 180 AP:
Dimensions (H x W x D):
82 x 72 x 67 mm
Output:
Filament bulbs, 1000 W max., operating on 230 V AC
Fluorescent lamp, 500 W max., at cos ϕ = 0.5,
inductive load at 230 V AC
4 x 58 W each max., C ≤ 88 μF
operating on 230 V AC
Connection: 230 V, 50 Hz
3-lead connection (L, L', N)
Contact gap: , contact clearance of less than 1.2 mm between the
contacts when unit is switched 'OFF'.
Installation height: approx. 1.1 and 2.2 m
Sensor technology:
Infrared sensor
Transmission output:
-
Angle of coverage:
180° with
90° angle of aperture
Reach: 8 m max.
Twilight setting: 2 - 2000 lux
Time setting:
10 sec. - 30 min.
Permanent light:
switchable (4 h)
Permanent light OFF: switchable
IP rating:
IP 54
*1)
Fluorescent lamps, low-energy bulbs, LED lights with electronic ballast
(total capacity of all connected ballasts below the value specifi ed).
*2)
Installation above a door.
HF 360 AP:
82 x 72 x 64 mm
*1)
*2) *2)
approx. 1.1 and 2.2 m
5.8 Ghz
High frequency
approx. 1 mW
360° with
140° angle of aperture
1 - 8 m
continuously adjustable
2 - 2000 lux
10 sec. - 30 min.
switchable (4 h)
switchable
IP 54
