Installation
Note for IR 180 AP: Connecting the supply
The installation position
lead to the basic element
should be at least 1 m from (refert to ill. on page 4):
a light, since heat radiation The mains lead consists of a
may trigger the system. 3 phase cable.
L = phase conductor
Installation procedure:
(usually black or brown)
1. Loosen housing screws N = neutral conductor
and open housing , (usually blue)
then loosen sensor unit L' = phase conductor
(screw) and remove (usually black or brown)
with the basic element
If in doubt, the cable must
. be identifi ed with a voltage
2. Hold base of housing on tester. Switch off the current
wall (with the inscription again. Phases (L) and (L')
TOP facing upwards) and in addition to the neutral
mark the drilling holes.
conductor (N) are connected
3. Drill holes with a 6 mm to the terminal block. A
bit. protective-earth conductor
4. Insert dowels in the is not required.
holes.
5. Screw the base of the
Important: Reversing the
housing in place with the connections may result in
enclosed screws. damage to the unit.
6. Strip the cable (approx.
70 mm) and remove 8. Insert basic element
approx. 5 mm of insula-
into the housing section
tion from the fl exible
ends. at bottom).
7. Push through sealing 9. Carefully push on the
plugs and pass the cable
sensor module
through (the cable sheath ing care not to jam) and
must be completely sur- screw to the housing
rounded by the sealing base section.
plug).
16
10. After the mains connec-
tion has been made, the
sensor switch can be
operated (refer to func-
tions section).
11. Finally apply the design
shade
place.
Note:
Parallel switching of
IR 180 AP and HF 360 AP
is possible. Nevertheless, a
neutral lead must be pres-
ent on each fl ush box. The
max. output to be switched
does not increase as a
result.
(terminal connection
(tak-
Functions
and screw in
1 - 8 m
Functions
2
2
Lux
LUX
2 - 2000 lux
10 sec. - 30 min.
Reach setting
(Sensitivity)
The term reach denotes
the approximately circular
diameter that results as the
detection zone.
Twilight setting
(Response threshold)
The desired sensor re-
sponse threshold can be
adjusted continuously from
approx. 2 lux to 2000 lux.
Adjusting screw right stop
position means: daylight
operation approx. 2000 lux
(factory setting).
Time setting
(Switch - off delay)
The desired duration of
illumination of the connected
light can be continuously
adjusted from approx.
30
10 sec. to max. 30 min.
Adjusting screw left stop
position means: shortest
time approx. 10 sec. (factory
setting)
Adjusting screw right stop
position means: longest time
approx. 30 min.
The timer is restarted by any
motion detected before this
time elapses.
(only for HF 360 AP)
Adjusting screw left stop
position means: minimum
reach (approx. 1 m / factory
setting).
Adjusting screw right stop
positon means: maximum
reach (approx. 8 m).
Adjusting screw left stop
position means: night-time
operation approx. 2 lux.
When adjusting the detec-
tion zone and for the per-
formance test in daylight,
the adjusting screw must be
set to the RH stop position.
The shortest time setting is
recommended when adjust-
ing the detection zone and
performing a functional test.
Note: After every 'OFF'
switching, further motion
detection is interrupted for
approx. 2 seconds. Only
after this time elapses is
it possible for the Sensor
Switch to switch light again.
