1. DESCRIPTION
(see front cover)
1. Antenna
2. Flashlight button
3. Lock button
4. Up/Down button
5. Call button
6. Speaker
7. Talk button

2. INSTALLATION

2.1. Removing/Installing the Belt Clip
• To remove the clip from the unit, push up on the belt clip while pulling
the clip tab. (1)
• When re-installing the belt clip, a click indicates the BeltClip is locked
into position.
2.2. Battery Installation
• Remove the belt clip (2).
• Pull the Battery Cover Tab (4) and remove the Battery Cover (3).
• Install four 'AAA' alkaline or rechargeable batteries following the
polarity as shown.
• Re-install the Battery Cover (3) and Belt Clip (2).
Topcom Twintalker 3300
8. Monitor button
9. Microphone
10. Menu button
11. On/Off button
12. LCD display
13. Flashlight
14. Ear/mic/charger
1
2
3
4
ENGLISH
3
