Expolite AKKULED MINI ZOOM Bedienungsanleitung Seite 34

34
3.14
OPERATION WITH WIRELESS DMX
Bei Nutzung des eingebauten W-DMX Empfängers achten Sie bitte
auf die begrenzte Reichweite. Diese ist Umgebungsabhängig und
kann variieren.
When using this lighting fixture with W-DMX receiver installed
inside, the fixture may be placed at a range of 300m from W-DMX
transmitter.
Select DMX from the RUN menu.
If the WDMX receiver card is already paired with a W-DMX
transmitter then the fixture is ready for receiving DMX signal. If
the W-DMX receiver card needs to be paired with a new W-DMX
transmitter, select YES from the WDMX / REST menu. The green
signal indicator LED will not show which confirms that W-DMX re-
ceiver card is unpaired and ready for new pairing. By pressing the
RESET button on W-DMX transmitter, transmitter will search for
RESET lighting fixtures. During search transmitter green SIGNAL
indicator will flash. After
pairing with lighting fixture
green SIGNAL indicator will
display.
Once a lighting fixture has
been paired with a W-DMX
transmitter, the green SIG-
NAL indicator will display.
Once a lighting fixture has
been paired with a W-DMX
transmitter, the lighting fix-
ture cannot be paired with
another W-DMX transmitter.
If a lighting fixture requires
pairing with a new W-DMX
transmitter, steps 5.3 and
5.4 must be repeated.
W-DMX TRANSMITTER
POWER
WIRELESS RECEIVING
ANTENNA
SIGNAL ANTENNA
RESET
STATUS LED
