Expolite AKKULED MINI ZOOM Bedienungsanleitung Seite 26

26
2.0 INSTALLATION
2.1
MOUNTING
UPRIGHT: The fixture can
be mounted in an upright
or sitting position using the
supporting brackets.
NOTE!
It is possible to further adjust the angle of the LED MODULE using
the two adjustment knobs located on the side of the fixture.
2.2
GENERAL OPERTAION
Press Menu-Button to switch device on
When charging, power light is red, when finish charging, power
light is green.
When turn on fixture, it´s static mode,
red light is off.
If no DMX signal when turn on fixture,
green light is always on.
When it´s under infrared mode
and there is infrared signal,
red light is flickering.
FUNCTION OF LIGHT
INFRARED RECEIVER
