Expolite AKKULED MINI ZOOM Bedienungsanleitung Seite 32

32
3.10
BALANCE PARAMETERS AND CORRECTION
MENU DISPLAY
To Enter Calibration menu enter the correct password
UP+DOWN+UP+DOWN
Enter CALIB.C to select white color of different color temperature.
There are 12 pre-programmed White colors can be edited by using
the COLORS.
Enter the RGBW to adjust the RGB parameter to make different
whites. When the new setting is activated, the DMX controller
choose RGB = 255,255,255 the white color will be made by the
actual RGB values on the RGBW.
MENU
CALIBRATION
3.11
INFO-MENÜ
Press ENTER and go to INFO, you can check VERSION.
MENU
INFO
****
WHITE WT. 01
WT. 02
WT. 12
RGB to W R. ( 0-255)
G. ( 0-255)
B. ( 0-255)
UC
RED
GREEN
BLUE
WHITE
AMBER
CYAN
UV
VERSION
R. ( 0-255)
G. ( 0-255)
B. ( 0-255)
W. ( 0-255)
