Table 14: atmosph. mix. setup
The atmosphere mixer allows the controller to operate the core of a smart complex
control system for any gas fired kiln. The basic operation modes are air excess,
stochiometric, cooling. In air excess mode the heat up power controls the amount of
gas (gas leads air by a ratio control). In stochiometric mode the heat up power
controls the amount of air (air leads gas). In cooling mode the cooling power controls
inverted the amount of air (gas closed)
.
00: tempCtrl 0 CH
(value range OFF, CH00 to CH09)
01: tempCtrl 1 CH
(value range OFF, CH00 to CH09)
02: tempCtrl 2 CH
(value range OFF, CH00 to CH09)
Selects the control channel which controls the temperature for this zone
03: atmosphere SP
(value range AIR/DRV to SP09)
Selects the setpoint representing the atmosphere
04: atmosphere AI
(value range OFF, IN00 to IN19)
no explanation available
05: air vol.0 SP
(value range OFF, SP00 to SP19)
06: air vol.1 SP
(value range OFF, SP00 to SP19)
07: air vol.2 SP
(value range OFF, SP00 to SP19)
Selects the process parameter representing the actual air flow for this zone
08: gas vol.0 SP
(value range OFF, SP00 to SP09)
09: gas vol.1 SP
(value range OFF, SP00 to SP09)
10: gas vol.2 SP
(value range OFF, SP00 to SP09)
Selects the process parameter representing the actual gas flow for this zone
40
Table 15: atmosph. mix. adj.
Fine tune parameters for the stochiometric mode of the atmosphere mixer
.
00: max pwr AIR
(value range 0.1 to 3000.0)
01: max pwr GAS
(value range 0.1 to 3000.0)
02: low pwr lim %
(value range 10 to 100)
03: combust. Cx
(value range 1.00 to 100.00)
04: combust. Hy
(value range 1.00 to 100.00)
05: combust. inert
(value range 0.00 to 50.00)
06: min tune range
(value range 0.00 to 1.00)
07: max tune range
(value range 0.00 to 2.00)
08: atms.integral
(value range 10 to 10000)
integral time for the atmosphere control loop
09: feedback lim %
(value range 0.0 to 12.5)
.
.
operating instructions bentrup TC-S2 V1.1
