during segment 0 and at the end of the firing) / 1=programme run (also ON during
segment 0) / 2=programme run / 3=end of the firing / 4=any channel error /
5=programme HOLD / 6=OFF / 7=ON / 10/11/12=mixer in air
excess/stochiometric/cooling mode / 13=programme continues after power
breakdown / 14=do0.6 and not do0.7 / 15=do0.6 and do0.7 / 16=not do0.6 and do0.7 /
17=control channel off band / 18=programme interrupted due to off band / 19=any
monitored channel error / 20=final temperature matches in all monitored channels /
21=any monitored channel in control range / 22=any monitored channel out of control
range
following parameters apply on selection EVE only:
43: EVENT number
(value range 0 to 10)
Digital output works as programme EVENT number #. This number must fit the EVENT
number specified in the programme table
44: output on IDLE
(value range 0 to 1)
Defines the state of the digital output when the controller is IDLE: 0 = OFF / 1 = ON
45: output on ERR
(value range 0 to 1)
Defines the state of the digital output when the controller enters a system error: 0 =
same as during programme run / 1 = OFF / 2 = ON
following parameters apply on selection TAB only:
53: table dat.src
(value range TA00 to TA19)
Select the column number of the programme table the programme value is taken
54: outp. width
(value range 0 to 8)
number of digital outputs in sequence used for this function
following parameters apply on selection CMB only:
63: combinat. type
(options OR, NOR, AND, NAND, XOR, XNOR)
Select the type of combinatoric operator applied to the selected bits
64: output on IDLE
(value range 0 to 2)
Defines the state of the digital output when the controller is IDLE: 0 = same as during
operating instructions bentrup TC-S2 V1.1
programme run / 1 = OFF / 2 = ON
65: output on ERR
(value range 0 to 2)
Defines the state of the digital output when the controller enters a system error: 0 =
same as during programme run / 1 = OFF / 2 = ON
66: 1. DOxx sel.
(value range DO0.0 to DO8.0)
67: 2. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
68: 3. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
69: 4. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
70: 5. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
71: 6. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
72: 7. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
73: 8. DOxx sel.
(value range OFF, DO0.0 to DO8.0)
Selects the bits (digital outputs) used in the combinatoric network. Set to "OFF" when
unused
Table 6: programme table
The programme table determines the parameters and the sequence to be entered for
each programme segment. The first programme parameter is always a time followed
by a temperature. Depending on the application the following programme segment
parameters could be for instance offset temperatures (for multizone kilns),
programme events etc. The parameter sequence after the 1st temperature is variable;
however, keeping all programme EVENTs togather saves programme memory
.
(options END, TIME, VAL!L, !!!, VAL!S, EVENT,
00: value type
ATMS)
Select the kind of value in each column of the programme table:
29
