Installation

Installation
NOTE:
The MultiPower-12-NT
The maximum power consumption permitted per device is 800 mA.
1. Use a power loop cable to connect one of the
compatible devices (12VDC/800mA) to one of
the twelve
Power Out
2. Connect one of the supplied power cables to the
socket.
Main Power
Connect the power cable to a power outlet.
3. If necessary, connect one of the supplied power
cables to the Red. Power
redundant power supply.
Connect the power cable to a power outlet of another power circuit.

Startup

1. Turn on the power switch of the internal
2. Turn on the power switch of the internal
NOTE: After you turn on the central power supply, the internal services of the cen-
tral power supply are started. Within approx. 60 seconds the outputs are turned
on successively.
3 · G&D MultiPower-12-NT
supplies up to twelve devices with 12 Volt.
sockets.
socket to establish a
Power Status
Power Out 1
Status
12VDC/800mA
Main Power
power pack.
Main Power
power pack.
Red. Power
M P -12-
ULTI OWER NT
Power Out 2 Power Out 3
Status Status
12VDC/800mA 12VDC/800mA 12VDC/800mA
Red. Power
