GB
If the fan increase or reduction buttons are pressed when the system is switched off, only the
evaporator fan is activated, with the choice of 6 different speeds, shown on the central control
unit display.
To switch off the fan it is necessary to set the value 0 on the central control unit display, using
the fan speed reduction button.
The save-battery function starts when the power falls below a value of 21,5V.
In this case, the system (AC or VENT) shuts down, also deactivating the fan function and the
message E1 appears on the display and the battery symbol lights up.
When the power returns, for at least 10 seconds, to the value of 25V, the system is
automatically reactivated, starting up the condenser fan, followed by the evaporator fan and
compressor.
Description
Battery voltage
(The battery-saver device has cut in. Voltage has fallen below the value of
21.5 V)
Fan over current cut-out
(The condenser or evaporator fan overloads the central control unit above
the limited allowed. Possible cause: short circuit or blockage of fan
rotation.)
Compressor locked
(The rotor is locked or the pressure inside the cooling circuit is too high.)
Minimum compressor rotation speed
(If the cooling circuit is overloaded, the compressor cannot maintain the
minimum rotation speed.)
High temperature on the central control unit
(If the cooling circuit is overloaded or the ambient temperature is high, the
central control unit signals this situation.)
Communication error
(There is no communication between the display and the central control
unit.)
Temperature probe
(If the probe short-circuits or is not connected, the system stops.)
Tilt
(The system shut-down device installed to operate in the event of tilting
has cut in. N.B.: The device only cuts in if the evaporator is installed
transversally to the direction in which the vehicle travels.)
The remote control regulates both the conditioning function and the fan function.
Using the remote control it is possible to:
- Switch the system on and off
- Regulate the temperature
- Regulate the fan speed
- Engage the MAX AC function
- Modify the TIMER function
VENTILATION (FAN)
SAVE BATTERY FUNCTION (AC / FAN)
ERRORS SHOWN ON THE DISPLAY (AC / FAN)

REMOTE CONTROL

Message Symbol
E1
E2
E3
E4
E5
E6
E7
E8
