eMitter Basic Bedienungsanleitung Seite 22

Pos. Title
1 Mains adapter
2 Connecting plug
3 Screw with dowel
4 Connector socket
5 Memory button
6 Arrow key „up"
7 Arrow key „down"
8 Delete button
9 Opening - and
programming
indicator
10 Display
1 1 Antenna
Control unit/ Functioning
Display
– Power supply
Angle plug Connection of the mains adapter
to the eMitter Display
– For wall-mounting the eMitter
Displays
Socket Connection of the mains adapter
to the eMitter Display
Short - stroke key - Programming traps
- Exit programming mode
Short - stroke key Increase memory slot number
Short - stroke key Reduce memory slot number
Short - stroke key Delete programming
Illuminating Opening states:
diode Green LED lights up: trap is empty
Red LED lights up: trap activated
Digital two- Display of the programming
digit display display
– Receipt of the transmitted signal
23
