These Instructions
contain the most important technical data and describe installation, operation and
é
commissioning of the keypad.
are only valid for keypads with the nameplate data: EPM-H310.
Description
The H310 keypad enables the user to access codes of Lenze controllers. Use the HMI
Designer to select the codes to be changed and code setting through the keypad.
Range of application
é
Applicable with the following controller series:
é
8200 frequency inverters (with function module AIF)
é
8200 vector frequency inverters
93XX servos
Connection with the controllers via system bus (CAN).
Accessories
Included in the delivery package:
- Two mounting clamps
- Two screws
- One gasket
- One terminal strip, 4-pole, for DC voltage supply
- One terminal strip, 5-pole, for system-bus connection
General data and application conditions
Display
Electrical connection
DC voltage supply
Power consumption
Insulation voltage to reference
earth/PE
Type of protection
System bus Protocol
(CAN) (CAN)
Communication medium
Network topology
System bus participants
Max. number of
participants
Baud rate [kBit/s]
Max. bus length [m]
Ambient temperature
Climatic conditions
Weight
Keypad EPM-H310
2 x 20 characters
Pluggable screw terminals
18 VDC ... 32 VDC
5 W at 24 VDC
50 V AC
IP65 (front)
CANopen
(CAL based communication profile DS301)
DIN ISO 11898
Line (terminated at both ends with 120 Ω)
Master or slave
63
20
2500
during operation:
during transport:
during storage
Class 3K3 to EN 50178 (without condensation, average
relative humidity 85 %)
0.5 kg
- 1 -
50 125
1000 500
0 ... + 50 °C
-20 ... + 60 °C
-20 ... + 60 °C
250 500
250 80
