INFORMATION
2.5.16 Schaltplan 230 V Wechselstrom / 50 Hz
ROTOR
Abb. 8: Schaltplan 230 Volt
16
STATOR
(10)
BATTERY
CHARGER
(10)
(1)
EXCITATION
WINDING
(2)
(3)
MAIN WINDING
(4)
(3)
MAIN WINDING
(4)
EARTH AND NEUTRAL CONNECTED
CURRENT
TRANSFORMER
RED BLACK
(11) (11)
DCC/ct-1
DCC/AC-1
YELLOW/GREEN
J1
ALT
REGULATOR
WCH
J2
ALT
CAPACITOR
CURRENT
TRANSFORMER
RED BLACK
(11) (11)
DCC/ct-1
DCC/AC-1
YELLOW/GREEN
230V 50Hz
L1
BROWN
PE
YELLOW/GREEN
N
BLUE
EARTH AND NEUTRAL
NOT CONNECTED
L1
BROWN
PE
YELLOW/GREEN
N
BLUE
Oktober 2004 / WHISPER 3,5 / DE
