Dear Customer,
We would like to take this opportunity to thank you for buying a new manual electrostatic gun.
We are confident that you have made the right choice.
We have taken every care, from original design to final manufacture, to ensure that this product
gives you complete satisfaction.
To obtain the best performance and reliability from this equipment, we would strongly advise you
to read this instruction manual attentively before attempting to use the equipment.
1. GENERAL SAFETY INSTRUCTIONS
1 -
The non-compliance with the safety requirements and precautions stated in this manual
could result in unsafe conditions.
2 -
The personnel involved in operating and servicing the electrostatic coating equipment must be fully
aware of all the safety requirements stated in this manual.
3 -
The workshop supervisor must be certain that the personnel has perfectly understood the safety
instructions and complies with them. These instructions cover the precautions required for solvent-
based paint spraying and the specific precautions in connection with the use of equipment requiring
high voltage.
The electrostatic coating system shall be used by qualified personnel only. The personnel must also
be familiar with the local safety standards which can be in force in certain coutries.
WARNING : failure to observe the safety precautions contained herein could result in
operating troubles and create unsafe conditions (body injury, explosion fire or electric
shock).
INSTALLATION
The EN 50 053 standard covers the select, installation and use requirements of the
electrostatic
The part 1 of that standard covers the paint electrostatic projection manual guns.
The KM.3 Ex gun is a gun designed only for the application of paints and varnishes.
4 -
Spraying, cleaning and servicing must be made in a ventilated area so that solvent vapours are
properly drained.
5 -
STD 9 power supply unit must be installed in a non-hazardous area. Moreover, it must be
located
4
meters
Ground the earth terminal.
6 -
All metallic parts located within 3 meters (10 ft) around the gun (such as pumps, drums, conveyor,
etc...) must be correctly grounded.
7 -
Storage of paint and solvent drums near or inside the spraying area is prohibited. Keep all fluid
containers properly closed in a non-hazardous area.
Use cleaning solvents with the highest flash point - If possible, higher than the ambiant
temperature.
8 -
Remove the useless parts from the spraying area and keep this area clean. Part holders and
conveyor hooks must be removed and frequently cleaned.
9 -
The floor must be electrically conductive and grounded. Maximum resistivity of the floor : 1 M as
per EN 50 053-7-2.
10 - The warning sign must be affixed in the spraying area and located where it can be easily seen and
read by all operators.
KREMLIN REXSON
projection
equipments
(13
ft)
at
least
away
Page 2
for
ignitible
from
any
flammable
Manual : 573.149.112
materials.
vapour
emissions.
