The Activated Charcoal Filter is only present on the Hoods in Recirculation version, and has
the job of retaining smells in the flow of air that passes over it, until reaching saturation. This
cannot be washed or regenerated, and must be changed when the 24H led on the display starts
to flash, or at least once every 4 months. The Alarm signal, if it has been activated, only
appears when the Suction motor is turned on.
Activating the alarm signal
• In Recirculation Version Hoods, the Filter Saturation Alarm must be activated on
installation or at a later date.
• Turn the Lights and the Suction Motor off.
• Press button E (Intensive) until confirmation is given:
• Motor Off Leds flash twice – Activated Charcoal Filter saturation alarm ACTIVATED.
• Motor Off Leds flash once – Activated Charcoal Filter saturation alarm DEACTIVATED.
CHANGING THE ACTIVATED CHARCOAL FILTER
Resetting the alarm signal
• Turn the Lights and the Suction Motor off.
• Press and hold button F (24H) for 2 seconds.
Changing the Filter
• Remove the Metal grease filters.
• Remove the saturated Activated charcoal filter, using the hooks
provided.
• Fit the new Filter, hooking it into place.
• Replace the Metal grease filters.
20 W halogen light.
• Remove the snap-on lamp cover by levering it from under the
metal ring, supporting it with one hand.
• Remove the halogen lamp from the lamp holder by pulling
gently.
• Replace the lamp with a new one of the same type, making
sure that you insert the two pins properly into the housings on
the lamp holder.
• Replace the snap-on lamp cover.
EN
Activated Charcoal Filter (Recirculation Version)
Lighting
LIGHT REPLACEMENT
