Description; Lcd Display Information - UCOM Twintalker 4710 Bedienungsanleitung

12 Description

See folded cover page - Illustration 1
1. TX LED
– Burns during transmission
2. Antenna
3. LCD Display
4. Earpiece connector
5. MENU button
– Enter the setting menu
6. DOWN button
– Decrease the speaker volume
– Select the previous value in the
menu.
7. CALL button

13 LCD Display information

See folded cover page - Illustration 2
15. Baby monitor icon
16. VOX icon
17. CTCSS code
18. Key Tone icon
19. Chronometer icon
20. Auto Power Off icon
21. Roger Beep icon
22. Volume icon
23. Key pad lock icon
24. Squelch Level indication
25. Call Tone icon
26. a. Scan icon
b. Dual Scan icon
27. Channel number / Volume level indication
28. Battery level indication
29. RX icon.
– Displayed when receiving
30. TX icon.
– Displayed when transmitting
UCOM Twintalker 4710 DCP
8. Speaker
9. SCAN/MONITOR button
10. Microphone
11. UP button
– Increase the speaker volume
– Select the next value in the menu.
12. Lock button
13. PUSH TO TALK button PTT
14. ON-OFF button
UCOM Twintalker 4710 DCP
9
